Sonic Hedgehog activates prostaglandin signaling to stabilize primary cilium length

During embryonic patterning, Sonic Hedgehog (SHH) family signaling proteins provide instructional cues that guide cell fate decisions to organize tissues. Disruption of SHH pathway activation leads to developmental disorders, and aberrant SHH activity drives cancer, underscoring the importance of tight signal control (Barakat et al., 2010). Accordingly, sophisticated regulatory mechanisms are in place to ensure appropriate pathway activity levels in both basal and activated signaling states. Pathway regulation requires localization of SHH signaling components to a specialized sensory organelle called the primary cilium (plural: primary cilia, both referred to as PC) (Caspary et al., 2007; Huangfu and Anderson, 2006). Each cell possesses a single PC that is anchored to the basal body and allows for the organization of numerous signal transduction cascades that instruct diverse cellular responses (Anvarian et al., 2019; Wheway et al., 2018). Despite the PC membrane being contiguous with the plasma membrane, it maintains a distinct membrane lipid composition through the action of lipid metabolic enzymes that localize near the ciliary base (Arensdorf et al., 2017; Findakly et al., 2021; Garcia et al., 2018; Raleigh et al., 2018). Further, a cytoplasmic diffusion barrier controls the entry of soluble proteins into the ciliary body, ensuring that the PC offers a protected environment for the interpretation and transduction of myriad extracellular signals (Garcia et al., 2018; Shi et al., 2017; Ye et al., 2013).

The SHH receptor Patched (PTCH), signal transducer Smoothened (SMO), and GLI2/GLI3 transcriptional effectors all function at or cycle through the PC in ligand-regulated manners (Arensdorf et al., 2016; Petrov et al., 2017). In the absence of SHH, SMO occupancy in the PC is blocked by PTCH-mediated depletion of SMO-activating sterols from the ciliary membrane (Kinnebrew et al., 2019, 2021; Kong et al., 2019; Myers et al., 2017; Zhang et al., 2018). In this off state, phosphorylation of GLI2 and GLI3 transcription factors by cyclic AMP (cAMP)-dependent protein kinase (PKA) tags them for partial degradation to remove their transcriptional activation domains (Bangs and Anderson, 2017; Haycraft et al., 2005; Tuson et al., 2011). SHH binding to PTCH attenuates PTCH-mediated ciliary sterol elimination. This leads to SMO-sterol binding, which promotes its accumulation in PC, where it signals to block PKA-promoted GLI truncation. This allows for the accumulation of full-length GLI2/3 proteins, which are subsequently activated for nuclear translocation and target gene induction (Niewiadomski et al., 2014; Umberger and Ogden, 2021).

Current models suggest the dependency of SHH signaling on PC evolved due to the specialized lipid composition of the ciliary membrane allowing for tight control over the availability of SMO-activating sterols (Kinnebrew et al., 2019, 2021; Kong et al., 2019; Raleigh et al., 2018). The small size of the PC allows for rapid modulation of second messengers including cAMP (Hansen et al., 2020; Truong et al., 2021). SHH signal output is highly sensitive to changes in ciliary cAMP concentration due to the key role that PKA plays in the regulation of PC-localized GLI (Mukhopadhyay et al., 2013; Truong et al., 2021; Vuolo et al., 2015). Accordingly, G protein-coupled receptor (GPCR) signaling can influence SHH pathway activity in both basal and activated states. In the absence of SHH, the Gα_s-coupled PC-localized GPCR GPR161 raises ciliary cAMP by stimulating ciliary adenylyl cyclases (AC). Pathway induction lowers ciliary cAMP by stimulating GPR161 ciliary exit (Mukhopadhyay et al., 2013). In addition, SMO can activate Gα_i-coupled heterotrimeric G proteins, which directly inhibit AC to pause cAMP production (Barzi et al., 2011; Ogden et al., 2008; Riobo and Manning, 2007). Thus, there are at least two direct routes by which SHH can lower ciliary cAMP to reduce PKA-directed GLI processing. How SHH-mediated reduction of PC cAMP impacts ciliary homeostasis or signaling by other PC-localized GPCRs has not yet been described.

A growing body of evidence supports that ciliary function and length stability require high ciliary cAMP. Studies in zebrafish demonstrate that multidrug resistance protein 4 transporter (MRP4/ABCC4), one of the MRPs that export the prostaglandin signaling molecule PGE₂, is required for motile cilium elongation and length stability (Cole, 2014). PGE₂ activates the Gα_s-coupled ciliary GPCR E-type prostanoid receptor 4 (EP₄), which raises intraciliary cAMP levels to promote anterograde intraflagellar transport (IFT) and maintain motile cilium length (Besschetnova et al., 2010; Jin et al., 2014; Marra et al., 2019). PC length control likely occurs through similar mechanisms because ABCC4 knockdown in cultured fibroblasts leads to PC shortening (Jin et al., 2014). This raises the possibility that ciliary cAMP reduction occurring in response to high-level activation of SHH signaling could slow IFT, shorten PC, and blunt the downstream signal response. The fail-safes that prevent ciliary shortening in SHH-stimulated cells are not known.

We previously reported that SHH activates cytosolic phospholipase A₂α (cPLA₂α) to produce arachidonic acid, which drives a feed-forward signal that enhances SMO ciliary enrichment. Inhibition of cPLA₂α attenuates agonist-induced SMO ciliary accumulation and blunts signaling to GLI transcription factors (Arensdorf et al., 2017). Arachidonic acid can be metabolized to generate the EP₄ agonist PGE₂, which led us to hypothesize that, in addition to enhancing SMO ciliary enrichment, SHH-mediated production of arachidonic acid may connect the SHH pathway with PGE₂/EP₄-regulated PC length control. We tested this hypothesis and mapped a communication relay between the SHH and prostaglandin signaling pathways that equilibrates ciliary cAMP for PC length homeostasis and SHH signaling competency. We demonstrate that genetic ablation or small-molecule inhibition of SHH-to-EP₄ crosstalk destabilizes PC cAMP levels, slows IFT, shortens PC, reduces SMO ciliary enrichment, and attenuates SMO signaling to GLI. Consistent with EP₄ signaling contributing to SHH pathway activation in vivo, mice lacking EP₄ have shortened neuroepithelial PC and exhibit neural tube patterning defects indicative of compromised SHH signaling. As such, we propose the SHH pathway linked with prostaglandin signaling through cPLA₂α activation to ensure PC length stability for optimal function of the organelle from which it instructs downstream signaling.

We previously reported that Gβγ signaling downstream of SHH-activated SMO stimulates cPLA₂α to produce arachidonic acid, which drives a feed-forward signal that promotes SMO ciliary accumulation (Arensdorf et al., 2017). To investigate how SHH-mediated cPLA₂α activation impacts ciliary length homeostasis, we used murine kidney inner medullary collecting duct (IMCD3) cells because they are SHH-responsive, have long PC, and provide an established model for examination of ciliary biology (Breslow et al., 2018; May et al., 2021; Ott and Lippincott-Schwartz, 2012; Zhou et al., 2014). To test whether SHH activation of cPLA₂α enhanced secretion of the arachidonic acid metabolite PGE₂, we measured PGE₂ levels in conditioned media collected from IMCD3 cells stimulated with control conditioned media or conditioned media containing the amino-terminal signaling domain of SHH for ∼36 h. Enzyme-linked immunosorbent assays (ELISA) of conditioned media detected PGE₂ in the absence of SHH and revealed a significant increase in PGE₂ levels following SHH exposure. The SHH-stimulated increase in PGE₂ concentration was blocked by pretreatment with the SMO antagonist LDE225 or the cPLA₂α-specific inhibitor giripladib (GIRI) (Fig. 1 A) (Arensdorf et al., 2017; Duvernay et al., 2015). Likely due to the activity of cPLA₂ isoforms that are not inhibited by GIRI, basal PGE₂ secretion was not reduced following GIRI treatment. As such, we conclude that the increased amount of PGE₂ that is released following SHH stimulation is produced from cPLA₂α-generated arachidonic acid.

The MRP ABCC4 contributes to PGE₂ release, ciliary elongation, and SHH signaling activity (Jin et al., 2014; Wijaya et al., 2020). Thus, we tested whether SHH-stimulated PGE₂ secretion occurred in an ABCC4-dependent manner by analyzing its release from control and SHH-stimulated Abcc4^−/− NIH-3T3 cells (Fig. 1 A′ and Fig. S1 A) (Wijaya et al., 2020). Similar to what was observed with IMCD3 cells, SHH stimulation of control NIH-3T3 cells increased PGE₂ levels in cell culture media. This increase was blocked by inhibiting SMO or the cyclooxygenase enzyme (COX) that initiates arachidonic acid to PGE₂ conversion (Fig. 1 A′, Coxib). Abcc4^−/− cells failed to increase prostaglandin release into media following SHH exposure (Fig. 1 A′). Importantly, PGE₂ secretion was rescued by expression of exogenous ABCC4 in Abcc4^−/− cells, suggesting that it is the primary MRP transporter responsible for PGE₂ release following SHH stimulation (Fig. S1 B).

A previous report demonstrated that Abcc4 knockdown reduced PC length in NIH-3T3 cells (Jin et al., 2014). Thus, we measured the lengths of PC in control and knockout cells and found that the average length of acetylated α-tubulin-labeled PC was significantly reduced in Abcc4^−/− cells compared with control NIH-3T3 fibroblasts (Fig. S1, C and D). Average PC length was restored by ABCC4 reintroduction, suggesting that the observed shortening was a specific result of ABCC4 loss (Fig. S1 D′). To probe the effect of ABCC4 loss on SHH signaling, we analyzed SMO ciliary accumulation as an indicator of signal initiation and GLI transcriptional activity as a read-out of downstream signal transduction. Intriguingly, SHH-stimulated SMO ciliary entry was maintained in Abcc4^−/− cells, indicating that initiation of the SHH signal response can occur in cells lacking ABCC4 function (Fig. 1 B). Despite this, SMO communication with GLI transcriptional effectors was compromised (Fig. 1 B′), which is consistent with defective downstream transduction of the SHH activation signal. Based on these results, we concluded that ABCC4 transporter function contributes to ciliary length maintenance and SHH signal transduction downstream of SMO.

Our previous work demonstrated that activation of cPLA₂α promotes SMO PC enrichment and signaling (Arensdorf et al., 2017). To determine whether cPLA₂α also contributes to ciliary length maintenance, we tested the effect of cPLA₂α inhibition on IMCD3 PC length. IMCD3 cells were treated with vehicle or GIRI in the absence and presence of SHH, and lengths of acetylated α-tubulin-marked PC were measured. Inhibition of cPLA₂α shortened PC significantly in both basal and SHH-stimulated conditions. The average PC length was ∼5 μm in the absence of GIRI and was reduced by ∼40% to ∼3 μm at the highest drug concentration used (Fig. 1, C and C′). PC length of GIRI-treated cells was rescued by the addition of supplemental PGE₂ or its precursor arachidonic acid, supporting the specificity of GIRI effects and suggesting that cPLA₂α promotes ciliary length control through arachidonic acid production (Fig. 1, D and D′; and Fig. S1, E and E′, columns 5–7). Notably, supplemental arachidonic acid augmented ciliary length in SHH-stimulated cells, further supporting the hypothesis that there is a correlation between increased arachidonic acid availability and PC elongation (Fig. S1 E′, column 2 versus 3–4). Taken together, these results suggest that the PC shortening observed in GIRI-treated cells was a specific effect of compromised arachidonic acid-to-PGE₂ metabolism.

To determine whether cPLA₂α inhibition impacted SMO ciliary accumulation in IMCD3 cells, we stimulated cells with SHH-conditioned media in the absence or presence of GIRI and then quantified SMO ciliary signal intensity. Consistent with what we observed in NIH-3T3 cells (Arensdorf et al., 2017), cPLA₂α inhibition reduced SMO ciliary occupancy in SHH-treated IMCD3 cells (Fig. S1, F and F′, red). SHH-stimulated ciliary exit of GPR161 (magenta) was unaffected by GIRI treatment (Fig. S1, F and F′), suggesting that the effects of cPLA₂α inhibition may be specific to SHH-promoted anterograde ciliary transport of SMO. Combined with the above, these results suggest that cPLA₂α-generated arachidonic acid contributes to SHH signaling in two manners: (1) it drives a feed-forward signal that promotes SMO ciliary accumulation (Arensdorf et al., 2017), and (2) it facilitates the production of PGE₂, which is secreted by ABCC4 to maintain ciliary length for robust SMO signaling to GLI.

Based on established connections between EP₄ and motile cilia elongation (Jin et al., 2014; Marra et al., 2019), we hypothesized that PGE₂ produced downstream of SHH activates ciliary EP₄ to influence PC length. Consistent with it being a ciliary GPCR, EP₄ was observed in PC of both IMCD3 cells and control mouse embryonic fibroblasts (MEF) and was not detected in cilia of Ep₄^−/− MEFs (Fig. 2, A–C′; and Fig. S2 A). To test the contribution of EP₄ to PC length maintenance, we compared the average ciliary lengths of control and SHH-treated IMCD3 cells exposed to vehicle or the EP₄ inhibitor, L161,982 (Cherukuri et al., 2007). Cilia of IMCD3 cells treated with increasing concentrations of L161,982 were shortened in a dose-dependent manner in the absence of SHH, and shortening was increased by SHH treatment (Fig. 2 D). Statistically significant ciliary shortening was also observed in SHH-stimulated NIH-3T3 cells treated with GIRI or L161,982 (Fig. 2 D′). This suggests that SHH stimulation compromises PC length maintenance if EP₄ activity is reduced. Importantly, supplementing the culture media of L161,982-treated IMCD3 cells with the EP₄ ligand PGE₂ partially rescued the ciliary length of SHH-stimulated cells (Fig. 2 E). This suggests that PC shortening following L161,982 treatment was a specific effect of on-target inhibitor activity toward EP₄.

To understand how EP₄ inhibition affected SHH signal output, SHH-stimulated SMO ciliary signal intensity was quantified in control, GIRI-treated, and L161,982-treated IMCD3 cells. Similar to what occurred following cPLA₂α inhibition with GIRI, inhibition of EP₄ with L161,982 attenuated accumulation of endogenous SMO in PC following SHH exposure (Fig. 3, A and B). Ciliary shortening and reduced SMO ciliary accumulation relative to control were also observed in Ep4^−/− MEFs (Fig. 3, C–E). Both PC length and SMO ciliary accumulation were restored by the reintroduction of EP₄ into Ep4^−/− MEFs (Fig. 3, D and E), supporting the hypothesis that the effects of L161,982 treatment on PC length and SMO ciliary accumulation resulted from on-target inhibition of EP₄. To determine whether reduced SMO ciliary enrichment following EP₄ inhibition compromised the activation of GLI transcriptional effectors, qPCR analyses of SHH transcriptional targets Gli1 and Ptch1 were performed in IMCD3 cells, NIH-3T3 cells, and Ep4^−/− MEFs. Inhibition of either cPLA₂α with GIRI or EP₄ with L161,982 significantly reduced the ability of SHH to activate a transcriptional response in IMCD3 and NIH-3T3 cells (Fig. 3, F and F′). SHH-stimulated target gene induction was similarly reduced in Ep4^−/− MEFs, despite the ability of PTCH1 and GPR161 to exit cilia of cells lacking EP₄ function (Fig. 3, G and G′; and Fig. S2, B–F′). Thus, compromised PGE₂/EP₄ signaling shortens cilia and attenuates downstream SHH pathway activity.

We hypothesized that coordinated GPCR regulation of ciliary cAMP production facilitates PC length homeostasis in SHH-stimulated cells (Fig. 4 A). To interrogate this hypothesis, we compromised ciliary cAMP production by knocking out the ciliary ACs Adcy3, Adcy5, and Adcy6 and the ciliary AC chaperone Ankmy2 using CRISPR/Cas9 (Fig. S3, A–B′) (Somatilaka et al., 2020). AC or ANKMY2 protein reduction in knockout cell pools was validated by Western blot, and ciliary AC signal reduction was assessed by analyzing colocalization with the ciliary resident protein ARL13B (Fig. S3, A′–B′). Notably, knockout of individual ACs reduced ciliary localization of the remaining ACs, which could indicate shared trafficking mechanisms (Fig. S3, B and B′). We used a PC-localized fluorescent sensor system to track ciliary cAMP changes in knockout cell pools and observed that loss of each of the ciliary Adcys and Ankmy2 blocked ciliary cAMP accumulation following IMCD3 treatment with the AC-stimulating drug forskolin (FSK, Fig. 4 B and Fig. S3, C–D′). Consistent with our hypothesis that reduced ciliary cAMP production leads to PC shortening, we observed statistically significant length decreases following knockout of Adcy3, Adcy5, Adcy6, or Ankmy2 (Fig. 4 C). PC length was restored in each of the knockout cell pools by supplementing culture media with the cAMP analog dibutyryl-cAMP (db-cAMP, Fig. 4 D), suggesting that ciliary cAMP reduction led to PC shortening following ciliary AC depletion. Consistent with cAMP effects on ciliary length occurring through EP₄ activation, control IMCD3 cells showed PC elongation following exposure to SHH and the EP₄ agonist PGE₂. PC elongation was also observed in Adcy3^−/− cells stimulated with PGE₂, but similar length increases were not observed in Adcy5^−/−, Adcy6^−/−, or Ankmy2^−/− cells, suggesting that cAMP produced downstream of SHH and PGE₂ occurs primarily through AC5 and AC6 (Fig. 4 D′, gray and pink versus yellow and blue). Taken together, these results suggest that SHH-promoted EP₄ signaling activates ciliary ACs to raise ciliary cAMP for PC length homeostasis.

To determine whether PC shortening in knockout cells correlated with reduced SHH pathway activation and downstream signaling, we compared SMO ciliary enrichment and target gene induction between control and knockout cell pools. Whereas SHH promoted PTCH1 exit and SMO ciliary accumulation in each of the knockout cell pools, the level of SMO ciliary enrichment was reduced compared with control cells (Fig. 4 E and Fig. S4 A). Notably, SMO was distributed along the PC membrane and was evident at PC tips in control cells exposed to either SHH or SHH + PGE₂, but did not efficiently spread along PC membranes in knockout cell pools in response to these ligands (Fig. S4, B and C). Curiously, the SMO ciliary enrichment that was observed in knockout cell pools treated with SHH or SHH + PGE₂ occurred near the PC base. Base accumulation was particularly pronounced in Ankmy2^−/− cells exposed to SHH + PGE₂, suggesting that pan-depletion of ciliary AC activity significantly stalls anterograde SMO ciliary trafficking (Fig. S4 C, arrows). Consistent with high-level SMO signaling requiring its accumulation throughout the PC, SHH-stimulated Gli1 transcriptional activation was reduced in knockout cells (Fig. 4 F). SHH-stimulated Ptch1 induction was also compromised, albeit to a lesser extent (Fig. 4 F′). Thus, we conclude that the ability to produce cAMP in the PC is necessary to stabilize ciliary length and promote SMO PC occupancy. When this capability is lost, SHH target gene activation is compromised.

Our observations that decreased IMCD3 ciliary AC occupancy correlated with reduced target gene induction were curious because ANKMY2 loss in vivo leads to SHH-independent GLI stabilization and increased transcriptional activity in the developing neural tube (Somatilaka et al., 2020). Thus, we expanded our evaluation to include highly SHH-responsive NIH-3T3 cells. We did not detect endogenously expressed Adcy6 transcript in NIH-3T3 cells, so we did not evaluate its knockdown in this cell type. Due to baseline PC lengths in NIH-3T3 cells being shorter than those of IMCD3 cells, length reductions occurring in response to ciliary AC depletion appeared modest. Nevertheless, we observed that knockdown of Adcy5 or Ankmy2 led to statistically significant reductions in average PC lengths in NIH-3T3 cells (Fig. S5, A and B). Adcy3 knockdown did not significantly alter NIH-3T3 ciliary length, suggesting that AC5 may be the primary modulator of cAMP-mediated PC length regulation in this cell type (Fig. S5 B). However, we did observe a modest reduction in SHH-stimulated Gli1 transcriptional activation following knockdown of either Adcy3 or Adcy5, suggesting that ciliary localization of both ACs may be necessary to optimize PC cAMP control for downstream GLI regulation in SHH-stimulated cells. Consistent with this hypothesis, Ankmy2 knockdown, which is predicted to cause pan-AC ciliary depletion, triggered a more pronounced reduction in SHH-stimulated Gli1 induction than that observed following a single AC knockdown (Fig. S5 C). These observations provide additional evidence that PC cAMP depletion can reduce PC length and blunt ligand-induced SHH signal output.

Having found that lowering ciliary cAMP via AC depletion shortens PC and attenuates SHH activity in IMCD3 and NIH-3T3 cells, we next tested whether SMO-regulated cAMP dynamics were influenced by EP₄. Because baseline ciliary cAMP levels were too low for the fluorescent ciliary cAMP reporter to detect cAMP reduction following SMO activation or EP₄ inhibition (Fig. S5 D), IMCD3 cells were stimulated with the AC activator FSK to raise basal cAMP prior to SMO stimulation (Fig. 5 A, red). Costimulation of IMCD3 cells with FSK and the direct SMO agonist SAG reduced the level to which FSK could raise ciliary cAMP, which is consistent with the ability of active SMO to couple with AC inhibitory Gα_i. Despite this, ciliary cAMP in cells treated with FSK + vehicle and FSK + SAG equilibrated similarly after an initial lag (Fig. 5 A, red versus blue). We hypothesized cAMP equilibration in SAG-treated cells was the result of EP₄ activation downstream of SMO-stimulated PGE₂ release. Accordingly, ciliary cAMP equilibration in SAG-stimulated cells was blocked by direct EP₄ inhibition with L161,982 (Fig. 5 A, green versus blue). Thus, we posit that EP₄ activation downstream of SMO contributes to the equilibration of PC cAMP levels in SHH-stimulated cells.

Previously published studies have indicated that EP₄ raises ciliary cAMP to promote anterograde IFT (Besschetnova et al., 2010; Jin et al., 2014). To determine if IFT was compromised by EP₄ inhibition in SHH-stimulated cells, we calculated the anterograde velocity of the ciliary transport protein IFT88 in control and L161,982-treated cells. We observed increased anterograde IFT in vehicle-treated, SHH-stimulated cells (Fig. 5 B, lane 1 versus 2). Anterograde IFT88 velocity was significantly reduced following treatment with the EP₄ inhibitor L161,982 in both control and SHH-stimulated IMCD3 cells (Fig. 5 B, lane 3 versus 4). These results suggest that EP₄ signaling maintains anterograde IFT in control cells and enhances its velocity in SHH-stimulated cells.

If the SHH-regulated cAMP equilibration that ensures IFT maintains PC length occurs through SHH-to-EP₄ crosstalk, we reasoned that supplemental ciliary cAMP should restore ciliary length and rescue SHH pathway induction following EP₄ inhibition. To modulate ciliary cAMP in a controlled manner, we used a published optogenetic AC system (Truong et al., 2021). IMCD3 cells were engineered to stably express either cytoplasmic or PC-localized bacterial photoactivatable adenylyl cyclase (bPAC)-GFP (Fig. S5, E and F). IMCD3 cells expressing cytoplasmic or ciliary bPAC proteins showed similar average PC lengths in the absence of blue light stimulation. PC lengths of cyto-bPAC-expressing cells did not change upon blue light exposure, despite increased cytoplasmic cAMP levels (Fig. S5, G–G″). Conversely, cilia-bPAC-expressing cells increased their average PC length by ∼30% upon blue light exposure (Fig. S5, G and G″), which is consistent with published evidence that PC-specific stimulation of cAMP production can enhance ciliary length (Hansen et al., 2020).

Having validated the feasibility of using ciliary bPAC to modulate IMCD3 cell PC length, we next investigated whether shortened cilia of EP₄-inhibited cells would elongate in response to cilia-bPAC induction. We observed that cilia-bPAC activation in L161,982-treated cells increased average PC length by 25% (Fig. 5 C, columns 2–3 versus 4–5). To test whether an increase in ciliary length correlated with the rescue of SHH pathway activity, we quantified SMO ciliary enrichment and GLI-mediated transcriptional activation following cilia-bPAC activation in the presence and absence of L161,982. Notably, SHH-stimulated SMO ciliary enrichment was significantly enhanced in vehicle-treated cells and partially restored in L161,982-treated cells in response to cilia-bPAC induction (Fig. 5 D, column 2 versus 5 and 3 versus 6). Despite this, the ability of SMO to induce GLI transcriptional activators following SHH or SAG treatment was blunted by cilia-bPAC stimulation (Fig. S5, H and H′). Similar to what has been previously reported, cyto-bPAC induction did not significantly alter the transcriptional response (Truong et al., 2021). These results, which are consistent with the established role of high ciliary cAMP promoting GLI repressor formation (Kong et al., 2019; Umberger and Ogden, 2021), suggest that an optimal balance of PC cAMP control must be achieved to maintain ciliary length homeostasis and anterograde SMO ciliary trafficking while allowing for downstream GLI activation.

Having established a cell biological connection between SHH and EP₄ that stabilizes PC length for optimal downstream signaling, we next sought to determine whether EP₄ loss altered ciliary length to impact SHH signaling in vivo. Thus, we analyzed developing neural tubes of Ep4^−/− mice to assess PC length and evaluate SHH-regulated ventral neural tube cell fate specification. Ep4^−/− mice are present at normal Mendelian ratios in utero but die at birth due to heart failure resulting from highly penetrant patent ductus arteriosus (Segi et al., 1998). Thus, we collected E9.5/25-29 somite stage wild type, Ep₄^+/− and Ep₄^−/− embryos to perform scanning electron microscopy for visualization of apical PC of cells lining the neural tube lumen (Fig. 6 A). Measurement of apical PC revealed that Ep4^+/+ and Ep4^+/− embryos had similar average ciliary lengths, but the average PC length observed in Ep4^−/− embryos was significantly reduced (Fig. 6, A and B). Whereas PC in control neural tubes averaged ∼0.9 µm, cilia in knockout embryos showed an ∼30% length reduction to an average of ∼0.6 µm. Thus, EP₄ contributes to PC length control in the developing mouse neural tube.

During neural tube development, SHH signals in a graded manner from the notochord and neural tube floor plate to instruct transcriptional programs that establish ventral neural tube cell fates (Ericson et al., 1997; Patten and Placzek, 2000; Ribes and Briscoe, 2009). To test whether EP₄ loss led to the alteration of SHH-dependent neural tube progenitor domain specification, we examined the expression of the ventral SHH transcriptional target Olig2, which is activated by high SHH, and the intermediate fate marker Pax6 (Fig. 6 C) (Ericson et al., 1997; Ribes and Briscoe, 2009). Quantification of ventral progenitor domain areas in E9.5/25-29 somite stage knockout and littermate control neural tubes using both manual (Fig. 6 C′) and automated (Fig. 6 C″) methods revealed that EP₄ loss led to a reduction in the Olig2-positive motor neuron progenitor cell population (Fig. 6, C–C″). This indicates a reduced SHH signaling response in Ep4^−/− mice. Although the Pax6-expressing progenitor domain did not significantly change in size, it shifted ventrally coincident with the reduction of the Olig2-positive progenitor population (Fig. 6, C′ and D). Taken together with the above, these results suggest that EP₄ loss shortens average PC length and compromises SHH-directed cell fate specification in vivo.

PC provide essential contributions to intercellular communication by housing numerous cell surface receptors and their downstream effectors (Hilgendorf et al., 2024; Mukhopadhyay and Rohatgi, 2014). Consistent with this functionality, the SHH pathway signal transducer SMO localizes to the ciliary membrane and communicates with GLI transcriptional effectors as they cycle through the PC (Arensdorf et al., 2016; Kong et al., 2019). We previously reported that cPLA₂α, which produces the PGE₂ precursor arachidonic acid, is a direct target of SMO-activated Gβγ. Arachidonic acid drives a feed-forward signal that promotes SMO ciliary enrichment and downstream communication with GLI (Arensdorf et al., 2017). Herein, we reveal that SHH-stimulated production of arachidonic acid also fuels PGE₂ production and secretion to activate EP₄ for PC length homeostasis and SHH signaling competency. This activity, along with the documented ability of noncanonical SHH signaling to stimulate primary ciliogenesis (Akhshi and Trimble, 2021), suggests that the SHH pathway has evolved multiple avenues by which it can ensure PC function for a robust signal response.

A key contribution of PC to the regulation of SHH pathway activity is to facilitate inhibitory GLI transcription factor phosphorylation by PKA in the absence of ligand and allow for a rapid halt of this activity in the presence of SHH (Kong et al., 2019; Umberger and Ogden, 2021). To pause PKA phosphorylation of GLI, SHH must lower ciliary cAMP levels. Accordingly, SHH signaling stimulates ciliary accumulation of Gα_i-coupled SMO and instructs PC exit of Gα_s-coupled GPR161 (Fig. 7, A and B). Although favorable for GLI stabilization, these responses risk depleting cilia of cAMP, which can slow IFT and destabilize PC length homeostasis. Consistent with this scenario, we and others have observed that SHH stimulation of cultured murine fibroblasts or IMCD3 cells can trigger modest reductions in ciliary length that occasionally reach statistical significance (this study and Gomez et al. [2022]). However, SHH-stimulated IMCD3 PC shortening does not exceed ∼12% unless SHH-EP₄ crosstalk is blocked, whereupon length reductions are consistently significant and range from ∼25 to 40%. Pronounced PC shortening following genetic or pharmacological EP₄ signal disruption correlates with slowing of anterograde IFT and a reduced SHH signal response (Fig. 7 C). We therefore propose that SHH-EP₄ crosstalk evolved to avoid these complications by equilibrating PC cAMP through EP₄-Gα_s activation of ciliary AC. Notably, SHH simulation leads to phosphorylation of the intracellular carboxyl-terminal tail of SMO by GPCR Kinases (GRK2/3) to expose a PKA inhibitory domain (PKI) that binds PKA to prevent GLI phosphorylation (Arveseth et al., 2021; Happ et al., 2022). We speculate this may be a mechanism by which GLI stabilization is maintained in SHH-stimulated cells following EP₄ activation and cAMP re-elevation.

Consistent with high PC cAMP and increased PKA activity favoring GLI repression, genetic loss of the ciliary AC chaperone Ankmy2, which prevents localized production of ciliary cAMP, triggers SHH-independent GLI accumulation and ectopic target gene induction in vivo (Somatilaka et al., 2020). Curiously, defective ciliogenesis was not observed in Ankmy2 knockout animals, and length reduction was not noted in NIH-3T3 cell systems used in the published report. We do not know the reason for the discrepancy between our results and theirs but speculate that differences in sample size or ciliary length measurement techniques may be contributing factors. Furthermore, PC shortening following cAMP dysregulation is subtle in NIH-3T3 cells, as demonstrated by the comparatively smaller length reductions we observed in NIH-3T3 versus IMCD3 cells following ANKMY2 loss or ciliary AC reduction. Nevertheless, both studies agree that Ankmy2 knockout cells are compromised in their ability to induce SHH-stimulated transcriptional responses. This suggests that the ability to precisely tune ciliary cAMP levels up or down is essential for optimal control of downstream SHH pathway activity. Consistent with this notion, we found that knockout of individual ACs reduced ciliary occupancy of other ACs and also blunted SMO accumulation along the length of the cilium. Both situations correlated with reduced target gene activation. Notably, loss of AC5, AC6, or ANKMY2 led to SMO accumulation near the PC base of SHH-stimulated cells in both the absence and presence of PGE₂, suggesting that depleting cilia of specific ACs stalls anterograde SMO IFT. This may indicate that specific ciliary cAMP “zones” generated by distinct ACs along ciliary membrane work together to promote IFT or regulate SMO signaling to GLI following SHH pathway activation. An alternative explanation is that rapid cAMP elevation that occurs through combined activity of all ciliary ACs may be needed to stimulate IFT following SHH pathway induction. Future studies are needed to evaluate these possibilities and determine the precise molecular mechanism(s) by which cAMP modulates IFT to promote SHH-stimulated SMO ciliary enrichment and downstream signal transduction.

Going forward, it will also be important to evaluate how specific signaling contexts influence the impact of cAMP on anterograde IFT and PC length stability. This is highlighted by a recent study that evaluated the use of optogenetic tools to modulate ciliary cAMP levels. It was reported that stimulation of PC-localized light-activated phosphodiesterase (LAPD), which is predicted to break down ciliary cAMP upon blue light exposure, did not reduce IMCD3 PC length (Hansen et al., 2020). This may indicate that reduced PC cAMP concentration is more detrimental to ciliary length regulation in the context of active signaling than it is when the PC is not engaged in a specific ligand response. Consistent with this hypothesis, we observed that ciliary length reductions triggered by inhibition of PGE₂/EP₄ signaling were exacerbated by SHH stimulation. It is also important to note that the LAPD used in the above-referenced study is activated by light stimulation at a wavelength that precludes concurrent use of PC cAMP biosensors (Hansen et al., 2020). Thus, PC cAMP could not be specifically evaluated following LAPD activation or at the time of ciliary length evaluation. We speculate that ciliary length may have shortened at earlier time points following LAPD activation or that compensatory ciliary AC activity was initiated to stabilize PC cAMP and length by the time cilia were measured.

Notably, the capacity of GPCR signaling to affect PC length behavior through cAMP modulation is not limited to SMO or EP₄. Activation of dopamine-stimulated DRD1-Gα_s signaling elongates cilia while activation of DRD2-Gα_i or MCHR1-Gα_i can shorten PC (Alhassen et al., 2022; Macarelli et al., 2023; Miyoshi et al., 2014; Spasic and Jacobs, 2017). These observations suggest that ciliary length modulation may be a common outcome of PC-localized GPCR activation. Although we do not propose that distinct SHH signaling thresholds are achieved at specific PC lengths, ciliary elongation resulting from genetic or pharmacological manipulation of actin polymerization has been demonstrated to amplify SMO signal output (Drummond et al., 2018). As such, we suggest that diminution of SHH pathway activity that occurs following EP₄ signal disruption can be attributed primarily to PC length reduction and not to generalized ciliary dysfunction resulting from EP₄ inactivity. Consistent with this hypothesis, a growing body of evidence demonstrates that distinct cell types have unique PC length ranges that, when altered, can impact signaling capacity (reviewed in Macarelli et al. [2023]). It is not yet clear how PC length affects signal output across cell types, but potential mechanisms include altering the sensitivity of cilia to extracellular cues, shifting receptor density along the ciliary membrane, or changing membrane receptor composition (Besschetnova et al., 2010; Macarelli et al., 2023).

Intriguingly, previously published work suggests that Gα_s-coupled ciliary GPCRs in addition to EP₄ may be activated in conjunction with SHH. Gα_s-coupled D1R and 5-HT₆ receptors also localize to PC and are sensitized to activation by their cognate ligands following SMO stimulation (Domire et al., 2011; Jiang et al., 2019). Whether these effects result from direct communication between SMO and other GPCR classes, or from ciliary GPCRs tuning their activity to fluctuations in PC cAMP concentration is not yet known. However, work in Drosophila suggests that GPCR signal crosstalk to raise cAMP downstream of Hedgehog (Hh) pathway induction may be conserved. In Drosophila, Hh-activated Smo stimulates Gα_i to lower cAMP and halt PKA-regulated truncation of the GLI ortholog Cubitus interruptus (Ci) (Ogden et al., 2008). However, PKA phosphorylation of Drosophila Smo is required for high-level signaling, suggesting that Gα_i-mediated cAMP lowering could compromise Hh pathway induction (Jia et al., 2004). A potential mechanism by which Smo solves this problem was revealed by the discovery that Smo signaling promotes Gα_s activation that enhances pathway responsiveness to low-threshold Hh stimulation (Praktiknjo et al., 2018). It is not yet clear whether Gα_s activation downstream of Hh occurs through Smo signal bias or by Smo crosstalk with Gα_s-coupled GPCR signaling partners. Nevertheless, the observation that Smo can lead to Gα_s activation in flies supports an evolutionarily conserved ability of Hedgehog family members to affect exquisite control of cAMP modulators to ensure appropriate downstream signaling activity. The model we propose (Fig. 7) highlights the complex relationship between SHH signaling and cAMP modulation and attempts to reconcile the seemingly incompatible pathway requirements of lowering cAMP to block GLI repressor formation while maintaining sufficient ciliary cAMP for functional ciliary trafficking, length homeostasis, and downstream SMO signal transduction.

All reagents, kits, primers, plasmids, mice, cell lines, antibodies, and software used in the study are detailed in Table 1, along with their source identification numbers.

L161,982, di-butyryl cAMP (dBcAMP), Sonidegib (LDE-225), and Celecoxib (Coxib) were reconstituted in DMSO and stored at −20°C. Arachidonic acid was reconstituted and stored in ethanol at −20°C. Prostaglandin E₂ (PGE₂) and Forskolin (FSK) were reconstituted in ethanol and stored at 4°C. GIRI was synthesized by WuXi and stored according to published procedures (Duvernay et al., 2015; Thotala et al., 2013).

Wild-type and Flp-In IMCD3, Adcy3^−/−, Adcy5^−/−Adcy6^−/−, and Ankmy2^−/− cells were cultured in Dulbecco’s Modified Eagle Medium (DMEM): F12 supplemented with 10% fetal bovine serum (FBS) and 1% penicillin/streptomycin solution (pen/strep, Gibco). Wild-type MEFs, NIH-3T3, Ep4^−/− MEF, and Abcc4^−/−-NIH-3T3 cells were cultured in DMEM supplemented with 10% fetal calf serum, 2 mM L-glutamine, 1 mM sodium pyruvate, 1× non-essential amino acids, and 1% pen/strep. Cells were passaged routinely with 0.25% Trypsin/EDTA solution and maintained under standard incubation conditions (5% CO₂, 37°C) in a humidified incubator. All cell lines were routinely tested for mycoplasma contamination. To promote ciliogenesis, cell lines were serum starved for 2 h in serum-free media (DMEM or DMEM: F12, supplemented with 0.1 mM nonessential amino acids, 2 mM L-Glutamine, 1 mM sodium pyruvate, and 1% pen/strep). After starvation, media was replaced with low serum (0.5%) media and cells were incubated for 18 or 36 h.

IMCD3 gene knockout pools were generated using CRISPR-Cas9 technology in the Center for Advanced Genome Engineering at St. Jude Children’s Research Hospital. Briefly, 1 million IMCD3 cells (ATCC) were transiently transfected with precomplexed ribonuclear protein (RNPs) consisting of 300 pmol of each Alt-R sgRNA (IDT) and 100 pmol of 3X NLS SpCas9 protein (St. Jude Protein Production Core) via nucleofection (Lonza, 4D-Nucleofector X-unit) using solution P3 and program DS-137 in a large (100 μl) cuvette according to the manufacturer’s recommended protocol. 3 days post nucleofection, cell pellets of ∼100,000 cells were lysed and used to generate gene specific amplicons that were sequenced via targeted next generation sequencing (NGS) as previously described (Narina et al., 2023). NGS data was processed using CRIS.py to report total editing for each pool (Connelly and Pruett-Miller, 2019). After expansion, the final pools were authenticated using the PowerPlex Fusion System (Promega) performed at the SJCRH Hartwell Center and tested negative for mycoplasma by the MycoAlertPlus Mycoplasma Detection Kit (Lonza). Knockout pools were further verified by Western blot. sgRNA spacer sequences and relevant primers are listed in Table 1.

EP₄ knockout cells were generated from Ep4^−/− embryos (Segi et al., 1998). Embryos (13.5 dpc) were freshly isolated and placed in individual 10-cm culture dishes where they were eviscerated. Heads were removed and used for genotyping to identify homozygous null embryos and wild-type littermates using conventional PCR. Embryo bodies were transferred to 15-ml conical tubes containing 5 ml fresh PBS and dissociated by aspirating through a 16-gauge needle into a 10 ml syringe and expelling the contents. Warm media (DMEM + 10% FBS + 1% pen/strep) was then added to each conical tube to bring the total volume to 10 ml. This solution was transferred to a 15 cm culture dish containing 25 ml additional media and placed in a 37°C incubator. After 24 h, media and non-adherent tissue pieces were removed and fresh media was added. Cells were grown to 80–90% confluence, after which they were passaged and frozen down after passage number two. Generation of Abcc4^−/− NIH-3T3 cells has been described previously (Wijaya et al., 2020).

IMCD3 cell lines stably expressing Cyto-bPAC-GFP and Cilia-bPAC-GFP were generated using the Flp-In system following manufacturer’s instructions (Thermo Fisher Scientific). IMCD3 Flp-In cells (Ye et al., 2013) were transfected using Lipofectamine 3000 with the appropriate plasmids and selected with 40 mg/ml hygromycin (Gibco). Single colonies were expanded, and protein expression was confirmed by fluorescence microscopy for GFP.

Cells were plated onto coverslips (Corning) and pretreated with either vehicle or drug in serum-free media. After 2 h, media was changed to low serum media containing vehicle or drug and SHH or control conditioned media (100 µl/ml) and then incubated for ∼18 h. After incubation, cells were washed with PBS and then fixed in 4% paraformaldehyde for 12 min. Cells were then washed with wash buffer (PBS with 0.1% Triton X-100) three times for 5 min and incubated in blocking buffer for 60 min at room temperature (PBS with 2% BSA, 0.1% Triton X-100, 1% goat serum). Primary antibody incubations were performed overnight at 4°C. The following antibodies and dilutions were used: anti-SMO (1:500; Santa Cruz), anti-acetylated α-tubulin (1:1,000; Cell Signaling), anti-ARL13B (1:500; Antibodies Incorporated or 1:1,000; BiCell Scientific), anti-EP₄ (1:100; Santa Cruz), anti-GPR161 (1:500), anti-AC5/6 (1:75; FabGennix), and anti-AC3 (1:200; Proteintech) diluted in blocking buffer. Secondary antibody incubations were performed with AlexaFluor 488, 555, or 647 conjugated secondary antibodies (1:1,000; Life Technologies) and DAPI for 60 min at room temperature. Following antibody incubation, samples were washed three times with the wash buffer followed by a PBS rinse prior to mounting with ProLong Diamond (Life Technologies). Images were collected using Leica TCS SP8 STED 3X confocal microscope with a 63× oil-immersion objective and processed using LAS X (Leica). For all immunofluorescence experiments, multiple cells (≥100) were examined over at least two independent experiments. Representative images are shown.

For ciliary length measurement, a maximum projection of the acquired Z stack images was created. Each cilium was manually traced from the base to the tip using the line profile tool in the LAS X software. To ensure an unbiased approach, subsets of PC length measurements were evaluated by a lab member who was blinded to experimental condition. For quantification graphs, all data are included. For microscopy images, representative cilia are shown.

Quantification of ciliary lengths and SMO, PTCH1, ARL13B, and GPR161 ciliary accumulation values were calculated from at least three independent experiments with at least 100 cilia per condition per experiment. A maximum fluorescence intensity projection from a sum of at least 10 slices was generated before length and ciliary intensity quantifications. SMO, PTCH1, ARL13B, and GPR161 ciliary signal intensities were normalized to acetylated α-tubulin or ARL13B signal. At least three randomly chosen fields of view were selected per condition per experiment, and all cilia within the field were quantified using LAS X. For ciliary SMO/PTCH1/GPR161/ARL13B signal intensity determination, each cilium surface area was traced from the base to the tip using spline profile function. The average fluorescence measurement adjacent to the cilium was subtracted from ciliary fluorescence as background. The intensity values along the cilium were exported and analyzed via GraphPad Prism. Colocalization of AC3 and AC6 with the PC marker ARL13B was carried out using the ImageJ plugin JACoP. Manders’ coefficients estimate the co-occurrence fraction of a fluorescent signal on one channel (ARL13B) with a fluorescent signal of another channel (AC3/AC5/6). Manders’ coefficients range from 0 to 1.

Percent EP₄ positive cilia were calculated by manually scoring EP₄ signal overlapping with the acetylated α-tubulin ciliary signal. Approximately, 75 cilia were scored over two independent experiments and all data were pooled.

Statistical analyses were performed using Prism 10 (GraphPad Software). Results are presented as mean ± standard deviation. For comparisons between two groups, a two-tailed unpaired t test was used unless otherwise specified. For multiple group comparisons, either one-way or two-way (depending on the number of variables) ANOVA followed by multiple comparison post-hoc testing was performed as indicated using Prism 10. Significance is depicted as *P < 0.05, **P < 0.01, ***P < 0.001, ****P < 0.0001, ns = not significant.

For Western blotting, SDS-PAGE samples were run on 4–15% Tris-glycine SDS-PAGE gels (Bio-Rad) and transferred onto Immobilon-P PVDF (Millipore) using Tris/Glycine/SDS Buffer (Bio-Rad) at 100 V for 1 h. Membranes were blocked with 5% milk in Tris-buffered saline with 0.1% Tween-20 (TBST) for an hour at room temperature. Antibody dilutions used were as follows anti-EP₄ (1:500; Santa Cruz), anti-ABCC4 (1:500), anti-AC6 (1:500; Proteintech), anti-AC3 (1:500; Abcam), anti-AC5 (1:500; Life Technologies), anti-ANKMY2 (1:1,000; Sigma-Aldrich), and anti-Kinesin (1:5,000; Abcam). Appropriate HRP-conjugated secondary antibodies (Jackson Immuno) were incubated for 1 h at RT at a 1:5,000 concentration. Blots were developed using an Odyssey Fc (Li-Cor) with ECL Prime (GE).

Cells including IMCD3 WT, Adcy3^−/−, Adcy5^−/−, Adcy6^−/−, Ankmy2^−/−, WT MEF, Ep4^−/−, and Abcc4^−/− were seeded onto coverslips in six-well plates and transfected with pCDNA3-eGFP, pCDNA3-Ptch1-GFP, pCDNA3-Arl13B-GFP, Tango-Ep4, or pKK44-Abcc4 (2 μg each) using Lipofectamine 3000 as per the manufacturer’s protocol. The next day, cells were serum-starved in serum-free media with or without drug treatment for 2 h. Media was replaced with low-serum media containing the indicated drug or vehicle control and SHH or control conditioned media (100 µl/ml) and then cells were incubated for ∼18 h. After incubation, coverslips were processed for the immunostaining protocol as described above.

Transfections using Lipofectamine RNAiMAX (Thermo Fisher Scientific) were performed following the manufacturer’s protocol. Briefly, NIH-3T3 cells were plated in six-well dishes at a density of 100,000 cells per well. The following day, cells were treated with 25 pmol of either scrambled or Adcy3, Adcy5, or Ankmy2 siRNA. Cells were analyzed 48 h after transfection.

bPAC-expressing IMCD3 Flp-In cells were plated onto coverslips, grown to confluency, and pretreated with either vehicle or L161,982 (10 µM) in serum-free media. After 2 h, the media was changed to low serum media containing vehicle or drug and SHH or control conditioned media (100 µl/ml) and then incubated for ∼18 h. Cells were transferred to a custom-made LED humidified incubator with 5% CO₂ for continuous blue light 450 nm stimulation at ∼0.4 mW/cm² for 3 h (Zhang et al., 2019). Following this, immunofluorescence staining was performed as described above.

Cells were cultured in 12-well dishes and pretreated for 2 h with either LDE225 (10 nM) or GIRI (2–4 µM) in serum-free media. Following pretreatment, media was changed to low-serum media containing either vehicle, LDE225, or GIRI plus control or SHH conditioned media, and then incubated for ∼36 h. PGE₂ levels were determined by ELISA (R&D Systems). The absorbance of each well was measured at 450 nm with correction at 540 nm.

For rescue experiments in Abcc4^−/− cells, cells were seeded in a 12-well culture plate and the following day they were transfected with either pcDNA3-eGFP or pKK44-Abcc4 (1 µg/well) using Lipofectamine 3000. The next day, cells were pretreated for 2 h in serum-free media. Following pretreatment, media was changed to low serum media containing SHH or control conditioned media, and cells were incubated for 36 h and PGE₂ levels were determined as described above.

cAMP in cell lysates was measured using the Direct cAMP ELISA kit (Enzo). Cells were seeded in six-well plates at a density of 3.5 × 10⁵ cells per well. The next day, cells were starved for 2 h in serum-free media followed by overnight incubation in low-serum media to promote ciliation. On the day of treatment, cells were treated with 100 μM IBMX diluted in low serum media and scraped into lysis buffer (0.1 M HCl; Enzo). Samples were analyzed per the manufacturer’s protocol. cAMP concentrations were calculated using a four-parameter logistic (4Pl) and normalized to the total protein concentrations, determined by a BCA protein assay (Thermo Fisher Scientific).

Cells were seeded at 18,000 cells/well in an eight-well chamber slide (Nunc Lab-Tek II Chamber Slide System) and transduced the next day with the ratiometric cilia-targeted cADDis BacMam (Montana Molecular) as per the manufacturer’s recommendation. Cells were infected with 20 µl of BacMam sensor stock in a total of 250 µl of media containing 2 mM sodium butyrate (Montana Molecular) for 30 min at room temperature in the dark followed by 5 h at 37°C. BacMam was removed and replaced with low-serum media containing 1 mM sodium butyrate for 16–24 h with or without vehicle or L-161,982 (10 μM). Prior to imaging, cells were incubated in PBS for 20 min at room temperature. Positive agonist FSK (100 µM) was added 30 s after the recording was initiated, and images were acquired on a Nikon A1R confocal on live cell imaging mode (60×, epifluorescence) every 10 s for 8 min while maintaining the cells in 5% CO₂ at 37°C on a heated stage (OKOLAB). For experiments with SAG, the signal was recorded for basal conditions followed by incubation with forskolin for 1.5 min and then treated with either SAG (1 μM) or vehicle and recorded every 10 s for 8 min.

For quantification of cAMP, the red fluorescence (ciliary reference marker) and green fluorescence (cAMP sensor) intensities over time were processed on the Nikon NIS-Elements imaging software by defining a mask for each cilium and determining the ratio of green fluorescence to red fluorescence. The data were normalized to the initial time point for each experiment (set to 100%), and the inverse of each value was plotted using GraphPad Prism.

Total RNA was extracted from cells using the RNeasy Mini Kit (Qiagen) according to the manufacturer’s protocol. 1000 ng of RNA was used to synthesize complementary DNA (cDNA) using High-Capacity cDNA Reverse Transcription Kit (Applied Biosystems). qRT-PCR reactions were performed on a QuantStudio 7 Flex PCR machine using PowerUp Sybr Green Master Mix (Applied Biosystems). Corresponding changes in the expression levels of selected genes were calculated using the ΔΔCt method relative to housekeeping genes, Ppia and Btf3 (Arensdorf et al., 2017).

For qRT-PCR analysis, IMCD3 WT, Cyto-bPAC, and Cilia-bPAC cells were seeded in a 12-well plate. The next day, cells were starved in serum-free media for 2 h, subsequently, the media was changed to low-serum media containing SHH-conditioned or control media or SAG (100 nM). After 18 h of incubation, cells were either treated with no light or blue light for an additional 3 h. Following this, RNA isolation and qRT-PCR were carried out as described above.

Kymographs for anterograde IFT88 velocities were generated in IMCD3 cells as previously described (Besschetnova et al., 2009). Briefly, 120,000 cells were grown on a coverslip in a 24-well plate. Cells were transfected with IFT88-GFP and 5HT6-mCherry plasmids the following day. Cells were pretreated with vehicle or the EP4 inhibitor L161,982 (10 μM) for 2 h and then switched to low serum media containing L161,982 either in the presence or absence of SHH or control conditioned media and incubated overnight. On the day of the experiment, the coverslips were flipped onto a two-well chamber slide (Nunc Lab-Tek II Chamber Slide System) and the cells were imaged every 200 ms for 30 s on a Nikon A1R confocal microscope with a 60× oil objective and 37°C, 5% CO₂ heat stage (OKOLAB). The resulting videos were analyzed by ImageJ macros KymographClear and KymographDirect to generate violin plots (Mangeol et al., 2016).

Data and materials generated from animals were obtained in accordance with SJCRH/IACUC approved protocol 608-100616-10/19 and Vanderbilt protocol M1600016-01. All animal husbandry and procedures were performed in accordance with protocols approved by St. Jude Children’s Research Hospital and Vanderbilt University Institutional Animal Care and Use Committees.

Ep4^+/+, Ep4^+/−, and Ep4^−/− embryos in the C57BL/6 background were harvested and processed for immunohistochemistry at E9.5/25-29 somites. Pregnant dams were harvested, uterine horns removed, and embryos dissected in 1X PBS, then rinsed three times in 1X PBS. Embryos were fixed overnight at 4°C in 4% paraformaldehyde (PFA). The following day, embryos were rinsed three times in 1X PBS and transferred to 30% sucrose to cryoprotect. The following day, embryos were frozen in O.C.T. Compound (Tissue-Tek) on dry ice. Embryos were sectioned transverse at 10 or 15 µm thickness on a Leica Microm CM1950 cryo-stat. Sections were briefly dried, then washed in 1X TBST, then blocked with 2% BSA, 1% goat serum, and 0.1% Triton-X-100 in 1X PBS. Antibodies were diluted in a blocking buffer and incubated overnight in sections at room temperature. The following antibodies and dilutions were used: mouse anti-PAX6 (1:10; DSHB) and rabbit anti-OLIG2 (1:300; Millipore). The primary antibody was removed, sections were washed with 1X TBST three times, and then incubated for 3 h in secondary antibodies (Invitrogen) at a 1:500 dilution. Sections were washed three times in 1X TBST, then rinsed with water, dried, and coverslips were applied with ProLong Gold mounting media with DAPI. Sections were imaged using an HC PL APO 20× NA 0.80 air objective on a Leica DMi8 widefield microscope equipped with a LED epi fluorescence illumination system, channel-specific filters for DAPI, 488, 561, and 647 compatible dyes, and a Hamamatsu Flash4.0 camera. A minimum of four embryos per genotype were analyzed.

All images analyzed are from the cardiac region adjacent to somites 2 and 3. The landmarks used to identify and align cardiac level transverse sections were the branchial pouches, aortic sac, and size/morphology of atria/ventricles. The Kaufman Atlas of Mouse Development Plate 19b images g and h show the region of the cardiac level images that were analyzed for expression domain quantifications (Graham et al., 2015).

To measure the total areas of OLIG2 and PAX6-positive neuronal progenitor domains, transverse cardiac level sections adjacent to somites 2 and 3 were analyzed by measuring the total progenitor marker expression domain area relative to the entire neural tube area. The area of the neural tube and the area of the progenitor domain were measured using the Segmented Line Tool in ImageJ. Expression domain areas were calculated by measuring the area of the indicated expression domain and normalizing it to the total area of the neural tube in each section analyzed (Hall et al., 2024). Three to five embryos were analyzed per genotype with five to eight sections analyzed per embryo.

To calculate the number of OLIG2 and PAX6 positive nuclei in the neural tube, raw fluorescent images were processed to identify the total number of cells (using DAPI nuclear stain) and the proportion of these nuclei co-occurring with OLIG2 (magenta) or PAX6 (green) signal in each tissue section after manual segmentation of the neural tube. Following upscaling of the raw data by a factor of 2× using Fiji, individual nuclear outlines were detected using StarDist on the fluorescent signal from the DAPI staining (Schindelin et al., 2012; Stevens et al., 2022). The resulting cell masks were used to measure the sum of fluorescent signals in each one of the two other channels (magenta and green). Results from the entire dataset (all conditions combined) were assembled and analyzed as a batch. Briefly, the distribution of the intensity of the fluorescence staining was plotted to evaluate the threshold values between negative and positive cell populations for each staining. These intensity thresholds were then applied across the entire dataset, and the results were formatted into a table reporting the total number of cells, the number of cells for OLIG2 (magenta), and the number of positive cells for PAX6 (magenta) for each neural tube analyzed. The graph is represented as a percentage of the positive nuclei for each domain normalized to the total DAPI positive nuclei in the neural tube of each section analyzed.

To quantify the relative position of OLIG2 and PAX6 expressing domains along the dorsal ventral (D/V) axis, at least three sections per embryo from the cardiac region adjacent to somites 2 and 3 were used. The total neural tube length from the floor plate to the roof plate was measured using the Segmented Line Tool in ImageJ. The length of the individual progenitor domain along the D/V axis was drawn using the Segmented Line Tool in ImageJ noting the distance of the boundary of the domain from the roof plate and from the floor plate to give domain length and position along the D/V axis (Hall et al., 2024). The graph demonstrates the relative position of each domain within the neural tube. The data are presented as mean ± SD, and statistical comparisons were made using one-way ANOVA. GraphPad software was used for statistical analysis. P values <0.05 were considered statistically significant.

For electron microscopy of neural tube PC, samples were fixed in 2.5% glutaraldehyde, 2% paraformaldehyde in 0.1 M cacodylate buffer containing 2 mM MgCl₂. Following fixation, samples were dissected to expose the interior of the neural tube lumen. Dissected samples were buffer washed, post-fixed in 0.1% aqueous osmium tetroxide for 1 h, washed with ddH₂O, dehydrated with an ascending ethanol series, and critical point dried in liquid CO₂ using an Autosamdri 931 (Tousimis). Dried samples were sputter-coated under planetary rotation with 15 nm iridium and imaged in a Thermo Fisher Scientific Teneo scanning electron microscope at 2 kV using the Everhart-Thornley and T1 detectors.

All statistical analyses were performed using Prism 10 (GraphPad Software). Results are presented as mean ± standard deviation. For comparisons between two groups, Student’s t test was used. For multiple group comparisons, one-way ANOVA followed by multiple comparison post-hoc testing was performed as indicated using Prism 10. Significance is depicted as *P < 0.05, **P < 0.01, ***P < 0.001, ****P < 0.0001, ns = not significant.

Fig. S1 provides further validation of the effects of ABCC4 knockout on PGE₂ secretion and primary cilium length and demonstrates that exogenous arachidonic acid (AA) can partially rescue ciliary length reduction following cPLA₂ inhibition with GIRI. Fig. S2 shows the effect of EP₄ knockout on PTCH1 and GPR161 ciliary localization. Fig. S3 shows AC protein reduction in knockout cell pools and provides validation for the fluorescent ciliary cAMP sensor used in the study. Fig. S4 shows the effect of AC knockout on PTCH1 and GPR161 ciliary localization. Fig. S5 provides validation of Adcy or Ankmy2 knockdown in NIH3T3 cells and shows the effect of knockdown on primary cilium length and Gli1 transcriptional activation. The effect of cytoplasmic and ciliary cAMP modulation by photoactivatable AC on ciliary length and SHH target gene activation is also provided.
