The ciliary transition zone (TZ) is a complex structure found at the cilia base. Defects in TZ assembly are associated with human ciliopathies. In most eukaryotes, three protein complexes (CEP290, NPHP, and MKS) cooperate to build the TZ. We show that in Drosophila melanogaster, mild TZ defects are observed in the absence of MKS components. In contrast, Cby and Azi1 cooperate to build the TZ by acting upstream of Cep290 and MKS components. Without Cby and Azi1, centrioles fail to form the TZ, precluding sensory cilia assembly, and no ciliary membrane cap associated with sperm ciliogenesis is made. This ciliary cap is critical to recruit the tubulin-depolymerizing kinesin Klp59D, required for regulation of axonemal growth. Our results show that Drosophila TZ assembly in sensory neurons and male germ cells involves cooperative actions of Cby and Dila. They further reveal that temporal control of membrane cap assembly by TZ components and microtubule elongation by kinesin-13 is required for axoneme formation in male germ cells.
Cilia and flagella are highly conserved organelles involved in various cellular and physiological processes. Defects in cilia assembly are responsible for many human diseases (Badano et al., 2006; Baker and Beales, 2009; Brown and Witman, 2014). Cilia are built around a microtubule core, the axoneme, which grows from the basal body (BB), itself derived from the mother centriole. At the interface between the BB and the plasma membrane, a particular compartment, the transition zone (TZ), plays both structural and functional roles by regulating the traffic in and out of the cilium and by forming structural links between microtubules and the membrane (Hu and Nelson, 2011; Szymanska and Johnson, 2012). Several ciliopathies, such as the Joubert syndrome and the Meckel syndrome (MKS) or nephronophthisis (NPHP) are caused by defects in TZ components (Czarnecki and Shah, 2012).
TZ assembly is a complex process starting with the docking of the mother centriole to cytoplasmic vesicles and the timely and spatially ordered assembly of multiple proteins. TZ components have been extensively described in several organisms (Szymanska and Johnson, 2012). Genetic approaches in Caenorhabditis elegans (Williams et al., 2011) and biochemical approaches in mammalian cells helped to establish a first comprehensive hierarchy of these components (Chih et al., 2011; Garcia-Gonzalo et al., 2011; Sang et al., 2011). They fall into different modules, namely MKS, NPHP, and CEP290. Proteins of the MKS module colocalize and together contribute to the formation of the TZ in various organisms, from C. elegans to mammals. In C. elegans, MKS, NPHP, and CEP290 cooperate to assemble the TZ (Williams et al., 2011; Jensen et al., 2015; Schouteden et al., 2015; Yee et al., 2015). Upstream, MKS5 (mammalian Rpgrip1L or NPHP8) controls the assembly of the MKS and NPHP complexes on centrioles (Jensen et al., 2015; Schouteden et al., 2015; Li et al., 2016). However, variations exist between model organisms, and all TZ components are not conserved in all ciliated species. For example, MKS5 and several other NPHP proteins are absent from the Drosophila melanogaster genome (Barker et al., 2014). Additional components of the TZ have been identified, but their integration in the hierarchy of TZ assembly is not yet clear. For instance, Chibby (Cby) is a component of the TZ in Drosophila and vertebrates (Voronina et al., 2009; Enjolras et al., 2012; Lee et al., 2014; Shi et al., 2014), but how Cby contributes to TZ assembly remains to be characterized. Cby is absent from C. elegans and protozoa genomes (Enjolras et al., 2012). Dila (Azi1 in mammals) is also not present in C. elegans but is required for TZ assembly in Drosophila or for ciliogenesis in mammals and is also associated with centriolar satellites in vertebrates (Ma and Jarman, 2011; Hall et al., 2013; Villumsen et al., 2013; Chamling et al., 2014). Therefore, key components of TZ assembly in C. elegans or mammals such as MKS5 are missing in Drosophila, and the mechanisms of TZ assembly in this organism are largely unknown.
Two main ciliated tissues are found in Drosophila: sensory neurons, in which cilia are required for transducing most senses, and sperm germ cells (Gogendeau and Basto, 2010). Sensory cilia assembly relies on intraflagellar transport (IFT) and is hence compartmentalized in Drosophila (Han et al., 2003; Sarpal et al., 2003). In contrast, flagella assembly in male germ cells is IFT independent and said to be cytosolic (Han et al., 2003; Sarpal et al., 2003; Basiri et al., 2014; Avidor-Reiss and Leroux, 2015). Such cytosolic mode of assembly is also proposed in mammals for the formation of the sperm midpiece (Avidor-Reiss and Leroux, 2015). In Drosophila, cytosolic flagella extension takes place inside a membrane ciliary cap, which requires Cep290 for proper organization and architecture (Basiri et al., 2014). This membrane cap is built in G2 Drosophila spermatocytes, when all four replicated centrioles dock to the plasma membrane and grow a primary cilium. During meiosis, the four primary cilia are internalized together with centrioles, maintaining the membrane ciliary cap connected to the plasma membrane (Tates, 1971; Carvalho-Santos et al., 2012; Riparbelli et al., 2012; Jana et al., 2016).
Here, we show that MKS proteins are involved in Drosophila TZ assembly, but simultaneous removal of several MKS components only leads to very mild TZ and axonemal defects. Instead, deleting both Cby and Dila, two components of the TZ in Drosophila, leads to extremely severe TZ disorganization with complete loss of MKS components and severe reduction of Cep290. In absence of Cby and Dila, BBs fail to dock to the plasma membrane of spermatocytes and assemble the ciliary membrane cap required for sperm flagella elongation. In absence of this ciliary cap, aberrant growth of axonemal microtubules is observed in spermatocytes. We demonstrate that Klp59D, a kinesin-13 family member, is present at the ciliary cap and is required for proper and timely regulated growth of the axoneme. We therefore propose that the ciliary cap is necessary to restrict and timely coordinate ciliary component assembly in Drosophila spermatocytes.
Organization of TZ components in Drosophila
In mammals and C. elegans, three protein complexes (MKS, NPHP, and CEP290) have been shown to be key players of TZ assembly. CEP290 and most MKS module proteins are conserved in Drosophila, whereas most NPHP components are missing (Fig. 1 A). In addition, Cby and Dila, two proteins conserved in mammals, were shown to be located at the TZ and involved in cilia assembly in Drosophila (Ma and Jarman, 2011; Enjolras et al., 2012). To understand more precisely how these components work together, we tagged several MKS proteins and compared their distribution in relation to Cby and Dila. We previously showed that B9d1 colocalizes with Cby in embryonic sensory cilia (Enjolras et al., 2012). Here, we show that the other members of the MKS module, B9d2, Mks1/B9d3, Tectonic (Tctn), and Cc2d2a, are found at the TZ at the base of sensory cilia as illustrated in chordotonal neurons of the antennae (Fig. S1).
In male germ cells, a dynamic behavior of centrioles and cilia takes place (Fig. 1 B). In midstage spermatocytes, all four centrioles dock to the plasma membrane and primary cilia like structures are extended at the surface of late spermatocytes (Tates, 1971; Carvalho-Santos et al., 2012; Riparbelli et al., 2012). Using superresolution 3D structured-illumination microscopy (3D-SIM), we observed that from early to late spermatocytes, Cby completely overlaps with acetylated tubulin (Fig. 2 A). Moreover, Mks1 (Fig. 2 D) colocalizes with Cby at the TZ. Membrane staining also reveals that Cby extends into the entire membrane cap in spermatocytes (Fig. 2 E). These results show that TZ and primary cilia are mingled at this stage, indicating that the primary cilium has a TZ composition.
The centrioles and cilia are next engulfed during meiosis (Tates, 1971; Fabian and Brill, 2012). In round spermatids, the centriole/BB still extends into the internalized ciliary membrane cap that is linked to the plasma membrane (Fig. 1 B). At the onset of flagellar axoneme elongation, the ciliary cap elongates and migrates opposite to the nucleus as a result of flagellum extension (Tates, 1971; Basiri et al., 2014). A particular structure called the ring centriole has been described in spermatids of many insects and corresponds to the base of the ciliary cap in elongating spermatids (Phillips, 1970; Fig. 1 B). Previous observations showed that the ring centriole is marked by Unc and Cby (Baker et al., 2004; Enjolras et al., 2012; Gottardo et al., 2013) and this is confirmed here by comparing Cby to acetylated tubulin staining (Fig. 2 A, spermatid).
To understand more in details the organization of the TZ in spermatocytes and spermatids, we used superresolution 3D-SIM. In spermatocytes, we observed that Unc marks the whole centriole and cilium/TZ. Moreover, Cby and Unc radially overlap in the cilium/TZ (Fig. 2 B, arrows), but Cby extends a little more distally to Unc. MKS components Cc2d2a, Tctn, B9d1, and Mks1 (Fig. 2, C and D) are restricted to the cilium/TZ, distal to the centriole (Asterless [Asl]), where they overlap with Cby. Dila distribution was found to be very different from other TZ components. It is localized inside the centriole and also inside the cilium/TZ lumen and capped by Cby (Fig. 2 F). Dila also strongly stains an unknown round shaped structure (Fig. 2 F, arrowhead) at the base of some centriole pairs. Last, Cby is found more radially to Cep290 (Fig. 2 G).
In spermatids, a dynamic remodeling of TZ components is observed at the onset of flagella elongation: whereas Cby and a ring of Unc separate from the BB (Fig. 2 B, arrowhead) MKS components are redistributed all along the membrane cap that is extended at this stage, as observed both on high-resolution images (Fig. 2, C and D) and by live imaging (Fig. 2 E and Fig. S2). Note that costaining of MKS proteins with Cby showed that these components are enriched at ring centriole but also extend distal to Unc and Cby all along the ciliary cap. Dila is maintained, like Unc, at the BB, and a very small fraction of Dila is sometimes detected at the ring centriole, apposed to Cby (Fig. 2 F). Dila is disassembled from both the BB and the TZ soon after initiation of spermatid elongation. All other ciliary cap and ring centriole components (Cby, Mks1, B9d1-2, Tctn, Cd2d2A, and Unc) are disassembled from flagellar tips at the onset of sperm individualization.
Absence of Drosophila MKS module at the TZ only mildly affects cilia assembly
To understand the function of the MKS module, we created by CRISPR-Cas9–mediated homologous recombination a null allele of simultaneously B9d2 and tectonic (tctn), as these two genes overlap in the genome (Fig. 3 A). B9d2, tctnΔ flies are viable and do not show sensory behavioral defects. Males produce motile sperm and show only slightly reduced fertility (mean progeny per male: 99 [control] and 84 [B9d2, tctnΔ]; Fig. 3 B). In agreement with these observations, ultrastructural analysis of the antennae chordotonal cilia did not reveal structural defects of the axoneme or of the TZ (Fig. 3 C). We still observe transition fibers and Y-like linkers connecting, respectively, the centriole or axoneme to the plasma membrane in both control and B9d2, tctnΔ flies. However, because these structures are difficult to observe in Drosophila, we cannot totally exclude that subtle ultrastructural defects could occur in absence of the MKS complex. In contrast, sperm flagella show weakly penetrant but statistically significant ultrastructural defects (Fig. 3 D). Approximately 10% of sperm flagella are broken or disorganized (Fig. 3 E), showing that Tctn and B9d2 are somehow involved in building stable axonemes.
We next analyzed the molecular organization of the TZ in absence of B9d2 and Tctn (Figs. 4 and S1). Cby and Cep290 are still recruited at the TZ (Fig. 4, A and B). We measured both the length of the centriole, labeled for Asl, and the length of the TZ labeled with Cep290 or Cby in absence of B9d2 and Tctn (Fig. 4 C), and we observed a small but significant decrease of TZ length that was correlated with an increase in centriole size. Strikingly, we observed a complete disruption of the MKS complex, as Mks1 and B9d1 are not recruited to the TZ in B9d2, tctnΔ spermatocytes (Fig. 4, D and E). B9d1 localization was rescued by reintroducing both tctn and B9d2 (Fig. 4 F). This shows that B9d2 and Tctn proteins are required to organize the MKS complex and that the absence of several proteins of the MKS complex at the TZ is largely dispensable for cilia assembly (Fig. 4 G). Based on this observation, we conclude that the MKS complex alone has only a subtle role in the organization of the TZ and ciliary cap in Drosophila sperm cells.
Cby and Dila cooperate to build the Drosophila TZ
In contrast to the weak impact of MKS protein deficiency on TZ assembly, mutations in proteins localized at the ring centriole lead to more severe phenotypes. Mutations in unc, cby, dila, or cep290 provoke marked uncoordination phenotypes caused by defects in ciliated neurons of the peripheral nervous system and show severe male infertility (Baker et al., 2004; Ma and Jarman, 2011; Enjolras et al., 2012; Basiri et al., 2014). Defects in Unc, Cby, and Dila lead to marked disorganization of sensory cilia, but BB still dock and build a TZ with only mild (Unc and Cby, showing interrupted distal segment of the TZ) or even no ultrastructural defects (Dila). The ultrastructure of sensory cilia was not investigated in cep290 mutants. In spermatids, loss of Cep290 modifies the MKS protein distribution at the ciliary cap (Basiri et al., 2014).
Strikingly, when we combined cby and dila mutations, we observed severe consequences on the function and architecture of sensory neurons. Flies are completely uncoordinated and cilia are absent in chordotonal neurons as observed by immunofluorescence (IF) and EM analyzes (Fig. 5, A and B). Centrioles fail to build a TZ (Fig. 5, B and C), and Cep290 and Mks1 are absent at dendritic tips (Fig. 5 E). In dila81; cby1 double mutants, we did not manage to observe typical features of docked BB such as transition fibers, present both in control or cby1 mutant flies (Fig. 5 C). However, centrioles are present at the tip of the dendrites and apparently show distal projections but are not connected to the membrane (Fig. 5, C and D). This phenotype differs from observations of mutants of genes encoding centriolar proteins, such as plp, for which all BBs fail to reach the distal part of the dendrite (Galletta et al., 2014).
Altogether, these results show that Cby and Dila cooperate to build the TZ and recruit most described TZ components in Drosophila sensory neurons (Fig. 5 F).
In double dila81; cby1 mutant flies, in addition to strong sensory defects, males are completely sterile. No mature sperm is produced and examination of testes shows that sperm cysts failed to elongate whereas the overall size of the testes is not reduced (Fig. 6 A). EM examination of testes indicates a severe disorganization of sperm cysts (Fig. S3 A). Most axonemes were absent or completely damaged. Because cysts were severely disorganized, we could only count the number of remaining axonemes relative to the number of major mitochondria derivatives. Out of 442 mitochondria, only 5 intact axonemes (1.2%) and 28 recognizable but destroyed axonemes (6.3%; Fig. S3 A) could be identified. These observations indicate a strong genetic interaction between cby and dila in flagella formation, as we observed only a small fraction (14%) of defective flagellar axonemes in cby1 mutants (Enjolras et al., 2012) and no axonemal defects were described in dila81 mutants (Ma and Jarman, 2011).
In the absence of both Cby and Dila, we observed that Mks1 and B9d1 (Fig. 6 B) are absent at the tip of BB in Drosophila spermatocytes and spermatids. Cep290 was also almost completely lost (Fig. 6 C; greater than sevenfold reduction), whereas no differences in the overall expression levels of Mks1-GFP or Cep290-GFP could be detected in the testes by Western blot (Fig. S3 B). These observations again reveal strong genetic interactions between dila and cby as MKS proteins and Cep290 are still present in the single cby or dila mutants and their distribution is only slightly modified (Fig. S4). Only Unc was still present in absence of Cby and Dila (Fig. 6 D). However, Unc distribution was altered, with an expansion of its expression domain, suggesting a defective organization of the ring centriole and membrane cap in the dila81; cby1 double mutant. EM observations of the centrioles in Drosophila spermatocytes showed that centrioles did not form a primary cilium-like structure, failed to dock to the plasma membrane, and had an odd orientation inside the cell (Fig. 7 A). No ciliary cap was observed in spermatocytes. Centrioles were apparently normally formed, showing the regular triplet arrangement and the presence of the central tube (Fig. 7 A, a2 and a5, arrow). Strikingly, aberrant microtubule extensions from centrioles were observed (Fig. 7 A, a3, a4, and a6, arrowheads). The absence of docking of the centrioles to the plasma membrane was confirmed by live imaging of centrioles in spermatocytes (Fig. 7 B). In addition, we could confirm the absence of the ciliary cap in spermatids by detecting Rab8, which strongly labels the cap from end of meiosis to late elongation stages (Fig. S3 C). In dila81; cby1 spermatids, Rab8 staining was completely absent from BB distal ends, whereas Rab8 was not affected in dila81 mutants and present at the ciliary cap in a significant fraction (∼35%) of the spermatids in cby1 mutants (Fig. S3 C).
To understand the nature of the aberrant microtubule extensions observed in the double mutants, we labeled cells with markers of tubulin posttranslational modifications. We found that microtubule extensions were acetylated and glutamylated (Fig. 7 C). These modifications are hallmarks of stabilized microtubules but are not restricted to the axoneme. We thus used a reporter marker CG6652 tagged with GFP, which specifically labels the spermatid axoneme in Drosophila (this study). Strikingly, whereas this marker only labels the primary cilia in spermatocytes and the ciliary cap in round spermatids (Fig. 7 D), huge extensions are visualized on double mutants, both in spermatocytes and in round spermatids. These extensions are not visible in early spermatocytes and only appear at the time of maturation when centrioles should be docking to the plasma membrane. This shows that premature axoneme elongation is observed in spermatocytes when centrioles fail to dock to the plasma membrane. Altogether, our results demonstrate that Cby and Dila cooperate to build the TZ, which is necessary for the formation of the ciliary cap. In the absence of this ciliary cap, premature axoneme elongation takes place (Fig. 7 E).
Klp59D is present at the sperm ciliary cap and controls timely and proper growth of the axoneme
We hypothesized that premature axoneme elongation could be caused by defective microtubule dynamics at the tips of the centrioles and in particular by defective control of the balance between tubulin polymerization and depolymerization. Several proteins play a role in controlling tubulin assembly. In particular, members of the kinesin-13 family of proteins are known to be involved in regulating tubulin depolymerization (Moores and Milligan, 2006). In Drosophila, three kinesin-13 family members are present in the genome (Rogers et al., 2004; Hu et al., 2015). Mutations of Drosophila Klp10A lead to centriole defects characterized by centriolar fragmentation, increased centriole lengths, and reduced size of primary cilia-like extensions in spermatocytes (Delgehyr et al., 2012; Gottardo et al., 2013), but not to aberrant microtubule extensions. These defects are different from those observed in dila81; cby1 double mutants. Knockdown (KD) of the other two kinesin-13 proteins by RNAi in Drosophila showed that only reducing Klp59D led to shorten cysts, strikingly similar to cyst phenotypes observed in dila81; cby1 mutant (Noguchi et al., 2011; Fig. S5 A).
We looked for Klp59D distribution using a Klp59D::GFP reporter transgene on live testes cyst preparation. Klp59D::GFP showed a dynamic distribution during germ cell differentiation (Fig. 8 A). In early spermatocytes, Klp59D is present throughout the cytoplasm. During spermatocyte maturation, Klp59D is also enriched at the tips of the centrioles and at their bases in late spermatocytes. Close examination of late spermatocytes show clear enrichment of Klp59D in the ciliary cap protruding from the cell surface (Fig. 8 B). In elongating spermatids, Klp59D is concentrated at the ciliary cap and along the axoneme (Fig. 8 A). We next analyzed the function of Klp59D by expressing shRNA in Drosophila male germ cells. We observed that the distribution of MKS components, Dila, or Cby was apparently normal in Klp59D KD spermatocytes (Fig. 8, C and F), suggesting that Klp59D acts downstream of TZ components. In support of this hypothesis, the amount of Klp59D around centrioles is significantly reduced compared with Asl intensity in the absence of both Dila and Cby (Fig. 8 D). However, Unc distribution was strikingly modified in Klp59D KD cells compared with controls (Fig. 8 E). This phenotype is identical to the one observed in dila81; cby1 double mutants and was confirmed with CG6652::GFP labeling, showing huge axonemal extensions on many centrioles in Klp59D KD cells (Fig. 8 F). Using a cell membrane marker, we observed that the aberrant axoneme elongation was associated with impaired membrane cap formation in male germ cells (Fig. 8 G). Furthermore, EM observations of spermatocytes showed part of the centrioles with aberrant microtubule elongation and disrupted ciliary cap (Fig. S5 D). These observations indicate that membrane cap formation requires strict control of microtubule elongation. Additionally, EM analysis showed a severe disorganization of spermatid axonemes similar to defects observed in dila81; cby1 mutants. Very few axonemes were apparently normal, and most were missing or broken (Fig. S5, B and C). Altogether, our results show that Klp59D is required for timely control of axonemal growth during male germ cell differentiation. Removal of this protein leads to premature microtubule elongation, axonemal structural defects, and defective ciliary cap formation.
Here, we show that TZ assembly in Drosophila involves cooperative actions of Cby and Dila, both in sensory neurons and male germ cells. More importantly, we reveal that a timely control of the balance between membrane cap assembly by TZ components and microtubule elongation by kinesin-13 microtubule remodeling is required for proper axoneme formation in Drosophila male germ cells.
Flagella assembly in Drosophila male germ cells does not rely on IFT, as null mutations in IFT components have no consequences on flagella formation (Han et al., 2003; Sarpal et al., 2003). It is thus considered to be cytosolic, in contrast to the more widely conserved IFT-dependent ciliogenesis, which is said to be compartmentalized (Avidor-Reiss and Leroux, 2015). However, proteins of the ring centriole/TZ such as Unc, Cby, or Cep290 are required to compartmentalize the flagellar growing end in Drosophila through the formation of a ciliary cap (Baker et al., 2004; Enjolras et al., 2012; Basiri et al., 2014). The exact function of this ciliary cap is not clear (Avidor-Reiss and Leroux, 2015). It was proposed that the formation of the ciliary cap is associated with the formation of a diffusion barrier, which protects the ciliary end from cytoplasmic proteins (Basiri et al., 2014; Avidor-Reiss et al., 2015). Our results are in agreement with this hypothesis and suggest that the ciliary cap is required to create a specific environment that restricts axonemal growth, as precluding ciliary cap formation in dila81; cby1 mutants leads to aberrant microtubule extensions and unstable axonemes. On the other hand, our results show that unbalanced microtubule growth prevents ciliary cap formation. In agreement with this conclusion, previous work showed that treatment of spermatocytes with Taxol leads to Unc domain extension, associated with aberrant axoneme elongation and defective ciliary cap formation, when treatment was applied on spermatocytes before BB docking, but not when applied after BB docking (Riparbelli et al., 2013). Therefore, cytosolic ciliogenesis in Drosophila is regulated by a precise balance between microtubule extension from the centriole distal end and membrane cap formation.
This mechanism is apparently specific to cytosolic ciliogenesis. In dila81; cby1 sensory cilia, the total absence of the TZ is not associated with aberrant axoneme elongation. This also indicates that centriole docking in this tissue is a prerequisite to elongate the axoneme. Klp59D is not expressed in sensory neurons, and driving Klp59D shRNA expression in sensory neurons did not reveal any sensory defects. These differences could reflect particular properties of centrioles in Drosophila spermatocytes. Indeed, all four centrioles convert to BB in spermatocytes, whereas only the mother centriole does so in sensory neurons (Tates, 1971). Therefore, different sets of proteins should be involved in centriole maturation in spermatocytes compared with sensory neurons. Further work will be required to understand molecular differences between sperm and sensory basal bodies.
Another set of observations highlights the particular behavior of spermatocyte centrioles. Mutations in TZ proteins have shown that reducing the length of primary cilia-like/TZ in spermatocytes is associated with an increase in length of the centrioles. This was observed when removing Cep290 (Basiri et al., 2014), and we made identical observations on B9d2, tctnΔ mutant testes. Thus, reducing ciliary cap extension allows centriole elongation, suggesting a balance in centriolar extension controlled by the TZ. Such a balance was also revealed by removal of Klp10A, which leads to an increase in centriole elongation and in a simultaneous reduction of primary cilia/TZ extension (Gottardo et al., 2013). Hence, the kinesin-13 proteins Klp10A and Klp59D likely play complementary functions at the spermatocyte TZ by restricting, respectively, centriole elongation or TZ elongation.
The function of kinesin-13 family members in ciliogenesis is still unclear and sometimes contradictory. In protozoa, such as Giardia intestinalis, Leishmania, or Trypanosoma, removal of kinesin-13 leads to longer flagella (Blaineau et al., 2007; Dawson et al., 2007; Chan and Ersfeld, 2010) in agreement with a tubulin-depolymerizing function of these proteins. It has also been proposed that kinesin-13 proteins play a role in maintaining a free tubulin pool to promote axoneme assembly (Wang et al., 2013). However, recent studies suggest more complex roles of kinesin-13 members in cilia assembly. In mammals, Kif24 is required to regulate centriole length by interacting with CP110 (Kobayashi et al., 2011). Such a function is also true for Klp10A in Drosophila (Delgehyr et al., 2012; Franz et al., 2013). Thus, one possible explanation for the observed phenotype in the dila81; cby1 double mutant would be that CP110 is prematurely removed from centrioles, as Dila and CP110 have strikingly similar localization inside the TZ lumen (this study and Franz et al., 2013, respectively). However, complete removal or overexpression of CP110 in Drosophila did not lead to measurable ciliary defects and obviously did not lead to aberrant centriolar extensions in male germ cells (Franz et al., 2013). Therefore, modulation of CP110 activity cannot explain the aberrant axonemal growth observed in the testes in both dila81; cby1 mutants and Klp59D KD.
In Tetrahymena, kinesin-13 protein was shown to act as an axoneme assembly factor by regulating the levels of tubulin modification and in particular tubulin acetylation inside the cilia (Vasudevan et al., 2015). It is tempting to speculate that Klp59D could play such a function in the ciliary cap of the sperm germ cell. However, it is difficult to test this hypothesis, as quantifications of differences in tubulin modifications inside the ciliary cap by IF are difficult and biochemical quantification of tubulin modifications is limited by the huge amount of nonaxonemal (cytoplasmic) modified microtubules in male germ cells.
Our study reveals both analogies and differences in TZ assembly between Drosophila and other organisms. In mammals, MKS proteins play a critical function on TZ assembly and subsequently cilia function as revealed by human ciliopathies, in which these proteins are mutated (Garcia-Gonzalo et al., 2011; Czarnecki and Shah, 2012; Reiter et al., 2012). In C. elegans, mutations in the five core members of the MKS complex (Tctn, MKSR-1 [B9d1], MKSR-2 [B9d2], MKS1 [B9d3], and MKS6 [Cc2d2A]; Bialas et al., 2009; Williams et al., 2011; Yee et al., 2015) have no effect on cilia architecture and sensory function. However, functional interactions were revealed between them, as their localization at the TZ is interdependent. In addition, whereas no genetic interactions are revealed when looking at sensory functions, combining mutations in several of these genes led to modified lifespan, suggesting that MKS components cooperate in specific ciliary signaling functions in C. elegans. (Bialas et al., 2009). In Drosophila, our results indicate that, like in nematodes, the MKS complex has only subtle functions on TZ and cilia assembly and that MKS components exhibit functional interactions, as removing B9d2 and Tctn is sufficient to completely alter the recruitment of the other MKS members. In this context, we do not expect to reveal genetic interactions by combining other mutations in MKS components together with our B9d2, tctn mutant. Our observations therefore suggest that the hierarchy and function of MKS components are likely conserved between C. elegans and Drosophila.
In contrast, strong genetic interactions have been described between MKS and NPHP components in C. elegans. In particular, MKS5 (Rpgrip1L or NPHP8 in mammals) acts upstream of all other components to build the TZ (Fig. 1 A), and NPHP4 and 1 interact with MKS complex proteins to organize the TZ (Williams et al., 2011; Sung and Leroux, 2013; Yee et al., 2015). These NPHP members are not conserved in Drosophila. Therefore, other proteins should be required to organize the ciliary TZ upstream of the MKS complex in Drosophila. Among conserved candidates in other organisms, Cep290 is required to build the TZ in Drosophila, but MKS components are still assembled at the TZ in Cep290 mutants (Basiri et al., 2014), thus suggesting that other TZ components act upstream of MKS. Here, we demonstrate that cby and dila show strong genetic interaction in TZ assembly, whereas mutating each separately only shows moderate effects. These results highlight for the first time the synergistic roles of Cby and Dila in building the TZ.
Cby and Dila are not present in C. elegans but are conserved in mammals. In mouse, Cby plays an important role in motile ciliated epithelia, as demonstrated by the severe airway ciliogenesis defects observed in Cby knockout mice (Voronina et al., 2009; Burke et al., 2014). In mammalian cells, Cby is also required for primary cilia assembly (Lee et al., 2014). Interestingly, mammalian Cby is required to dock centrioles to the plasma membrane (Voronina et al., 2009; Burke et al., 2014), a function that is only revealed in Drosophila by removing both Cby and Dila (Enjolras et al., 2012; this study). Mammalian Cby is required for Rab8-mediated ciliary vesicle assembly (Burke et al., 2014), and we show here that Rab8 recruitment at the ciliary cap is also partially affected in cby1 mutant flies and strikingly completely abolished in dila81; cby1 double mutants. This suggests a conserved role of Cby in Rab8-associated membrane cap assembly from Drosophila to mammals and highlights that Dila is also required for this process in Drosophila. In mammals, Azi1 (Dila in Drosophila) is a centriolar satellite component required for centriole duplication, but it is also localized at centrioles and is required for cilia assembly (Hall et al., 2013; Villumsen et al., 2013; Chamling et al., 2014). However, its function in TZ assembly has not been investigated. In Drosophila, Dila is found restricted to the BB and TZ and is required for cilia assembly, but no specific defects of the TZ were detected in mutant flies (Ma and Jarman, 2011). Thus, our study in Drosophila reveals that Dila is also involved in building the TZ but that alternative pathways can compensate for Dila deficiency in TZ assembly. Such compensation mechanisms have also been proposed for Azi1 in mammals (Hall et al., 2013).
In conclusion, our study reveals critical genetic interactions between two yet-unrelated TZ proteins, Cby and Dila. Future work will be required to understand if such interactions are also conserved in mammals. This work also demonstrates that the formation of a ciliary cap is essential to coordinate ciliary assembly during cytosolic ciliogenesis by creating a biochemical environment that controls axonemal microtubule growth.
Materials and methods
Fly stocks and maintenance
The following lines were obtained from Bloomington Drosophila Stock Center: vasa::Cas9 (Bl#51323), UAS-Dcr2 (Bl#24648), and DonJuan::GFP (Bl#5417). The shRNA against Klp59D (v100530) was obtained from the Vienna Drosophila Stock Center. The Rab8::YFP strain was described previously (Dunst et al., 2015). The cby1 mutant and Cby::GFP and Cby::Tomato transgenes were also previously described (Enjolras et al., 2012). The bam-GAL4::VP16 construct was described previously (Chen and McKearin, 2003). The Unc::GFP transgene was a gift from M. Kernan (State University of New York, Stony Brook, NY; Baker et al., 2004) and Ana1::GFP and Cep290::GFP were gifts from T. Avidor-Reiss (University of Toledo, Toledo, OH; Blachon et al., 2009; Basiri et al., 2014). PLCδPH-mRFP stock was a gift from J. Brill (SickKids, Toronto, Canada; Wei et al., 2008). The dila81 mutant was provided by A. Jarman (University of Edinburgh, Edinburgh, Scotland, UK; Ma and Jarman, 2011). The flies were raised on standard media between 21°C and 25°C.
Drosophila reporter gene constructs
6xMycTag-SV40polyA fragment was amplified from pCS2+nlsMT plasmid (a gift from R. Rupp, Adolf-Buteland Institute, Munich, Germany) and cloned in the XbaI site of the pattB vector (Bischof et al., 2013). EGFP sequence was amplified from pEGFP-N1 plasmid (Takara Bio Inc.) and cloned in the KpnI site of the previous construct, in frame with the 6xMycTag sequence.
The Tomato sequence was obtained by PCR on the Zeo-TomatoNT-2 (a gift from R. Basto, Institut Curie, Paris, France) and further cloned in the KpnI site of the pattB plasmid. SV40polyA was amplified from pEGFP-N1 plasmid (Takara Bio Inc.) and cloned in the XbaI site of the previous plasmid.
mKate2 and SV40polyA fragments were amplified from pmKate2-N plasmid (Evrogen). The two fragments were further cloned in the XbaI site of the pattB vector.
For each gene, the entire coding and at least 1 kb of upstream regulatory sequences were cloned in frame with GFP in the pJT61 vector or in frame with mKate2 in the pJT82 vector. Integration platforms and primers used were Mks1::GFP (89E11 [III]): forward (F)-1, 5′-TAATTCGCGGCCGCCTCTTCGACTTTCTGCTGCA-3′ and reverse (R)-2, 5′-TAATTCGTCGACAAACTCAGCCTGGTAGTATGC-3′; B9d2::GFP (68D2 [II]): F-3, 5′-TAATTCGCGGCCGCCAGCTGCATTATCAAGTACACC-3′ and R-4, 5′-TAATTCCTCGAGCTTGAACTCCACGCCGTATTC-3′; tectonic::GFP (68D2 [II]): F-3 and R-5, 5′-TAATTCCTCGAGGAGGCAAAGTTGCATGGATC-3′; dila::GFP (89E11 [III]): F-6, 5′-TAATTCGAATTCCAGCATACCCACTCCGGATC-3′ and R-7, 5′-TAATTCCTCGAGTTTAACACAATAATCCTTGCG-3′; Klp59D::GFP (22A3 [II]): F-8, 5′-TAATTCAGATCTTGTGACTGACATCTCGGTG-3′ and R-9, 5′-TAATTCGCGGCCGCAGCTCGGATTCATCCAGCTCG-3′; cc2d2a::GFP (65B2 [III]): F-10, 5′-TAATTCCGGCCGGCCCTGCGAGAATTACCTAG-3′ and R-11, 5′-GAATTACGGCCGCTCCACCAATGGCACCATG-3′; unc::mKate2 (59D3 [II]): F-12, 5′-TAATTCGCGGCCGCGGAGTACTTCTGCGCCAGG-3′ and R-13, 5′-TAATTCGTCGACCAGGTTTATGCGTTTCCAG-3′; CG6652::GFP (53B2 [II]): F-14, 5′-TAATTCGGATCCAAGCTTGAAGCCCAATTCAA-3′ and R-15, 5′-TAATTCGCGGCCGCAGGTCCTGGCTCTTGTTGTCGT-3′.
For B9d1::Tomato (CG14870), the 2.9 kb BamHI–NotI fragment from the CG14870-6xMycTag reporter plasmid (Enjolras et al., 2012) was subcloned in pJT108 in frame with Tomato and integrated in platform 59D3 (II). All transgenic lines were obtained from BestGene Inc.
Generation of B9d2, tctn mutant
The mutant for B9d2, tctn (CG42730 and CG42731) was generated by CRISPR/Cas9 catalyzed homologous directed repair (Gratz et al., 2014). Two gRNA were selected using the http://tools.flycrispr.molbio.wisc.edu/targetFinder/ website: 5′-CCACGCAGCAGATACACCTGTCC-3′ and 5′-GTTGCGAGTTGCATAGATGATGG-3′ (protospacer adjacent motifs are underlined). Oligos were phosphorylated by T4PNK (New England Biolabs, Inc.) and annealed. Double-stranded 5′gRNA and 3′gRNA were cloned in the BbsI site of pBFv-U6.2 or pBFv-U6.2B vectors, respectively (Kondo and Ueda, 2013). 5′gRNA was further subcloned in the EcoRI–NotI sites of pBFv-U6.2B to express the two gRNAs from one vector.
The 5′ and 3′ homology arms were amplified by PCR and cloned, respectively, into the EcoRI–NdeI and SpeI–XhoI sites of pRK2 plasmid (Huang et al., 2008). The two vectors (gRNAs and homology arms) were injected into Vasa::Cas9 embryos. Flies were crossed to w; Bl/CyO virgin females and the offspring were screened for red-eyed flies. Homologous recombination was checked by PCR.
Drosophila testes squashes
For PFA fixation, testes from young adult flies or pupae were dissected in 1× PBS, fixed for 15 min in 1× PBS/4% PFA, squashed between the coverslip and slide, and frozen in liquid nitrogen. The coverslip was removed, and the slide was soaked for a few seconds in ethanol 100% at −20°C. Testes were permeabilized for 25 min in 1× PBS/0.1% Triton X-100 (PBT) and blocked for 1 h in PBT/3% BSA/5% NGS. Primary antibodies were incubated in blocking solution overnight at 4°C or 1 h at RT. For Klp59D staining, testes were first kept in 1× PBS for 1 h at 4°C to depolymerize cytoplasmic microtubules, followed by fixation.
Testes from young adult flies or pupae were dissected in PBS, opened with a tungsten needle on a slide, and squashed. Slide was frozen in liquid nitrogen and coverslip removed. Samples were fixed 10 min in methanol 100% at −20°C, washed in PBS and blocked for 1 h in PBS/0.1% BSA. Primary antibodies were incubated in blocking solution overnight at 4°C or 1 h at RT (4 h for acetylated tubulin). For acetylated tubulin, testes were kept in PBS for 1 h at 4°C to depolymerize cytoplasmic microtubules before fixation.
For both fixations, fixed testes were washed in PBS and incubated for 1 h in secondary antibodies diluted in PBS. Slides were washed in PBS, incubated in Hoechst 1/1,000 for 15 min at RT, washed in PBS, and rinsed in ultrapure water. Slides were mounted using Dako or Vectashield.
Antennae were processed as previously described (Vieillard et al., 2015). In brief, Drosophila heads from 38- to 45-h pupae were dissected in PBS, fixed for 1 h in PBS/4% PFA, and washed in PBS. Antennae were blocked for 1 h in PBS/0.3% Triton X-100/3% BSA/5% NGS and incubated in primary antibodies diluted in blocking solution for 48 h at 4°C. Samples were washed three times in PBS and incubated in secondary antibodies diluted in PBS for 48 h at 4°C. Antennae were washed three times in PBS and mounted in Vectashield.
The antibodies used were the following: mouse anti-Futsch (1/1,000 DSHB = 22c10), mouse anti–acetylated tubulin (1/100, clone 6-11B-1; Sigma-Aldrich), mouse anti–γ-tubulin (1/500; Sigma-Aldrich), mouse anti–polyglutamylated tubulin antibody (1/500, GT335; Enzo Life Sciences), rabbit anti-HRP (1/500; Jackson ImmunoResearch Laboratories, Inc.), rabbit anti-GFP (1/1,000; Abcam), rabbit anti-DsRed (1/2,500; Takara Bio Inc.), guinea pig anti-Asterless (1/45,000; gift from G. Rogers, University of Arizona, Tuscon, AZ; Klebba et al., 2013), rabbit anti-plp (1/1,000; provided by R. Basto, Insitut Curie, Paris, France; Martinez-Campos et al., 2004), mouse anti-Rab8 (1/500; BD), and rabbit anti-Klp59D (1/1,000; provided by O. Blard and K. Rogowski, Institut de Géntétique Humaine, Montpellier, France). Generation of B9d1 (CG14870) antibody was performed by Eurogentec by immunization of guinea pigs with the following two peptides: PGNEETTPPHEKHKQ and SAKESVPNAMDAKAT. Crude serum was used at 1/2,500 dilution.
The following secondary antibodies were used (all at 1/1,000 dilution): goat anti–mouse Alexa Fluor 488 or Alexa Fluor 594, goat anti–rabbit Alexa Fluor 488 or Alexa Fluor 647, donkey anti–rabbit Alexa Fluor 568, goat anti–guinea pig Alexa Fluor 488 or Alexa Fluor 594 (Invitrogen), and donkey anti–guinea pig Alexa Fluor 647 (Jackson ImmunoResearch Laboratories, Inc.).
All acquisitions were performed at RT. Most slides were imaged using an IX83 microscope (Olympus) equipped with an iXon Ultra 888 EMCDD camera (Andor Technology) and IQ3 software (Andor Technology). A Plan-Apochromat N 60× 1.42 NA objective (Olympus) was used for all acquisitions. Some slides were imaged using an SP5X confocal laser scanning microscope (Leica Biosystems) equipped with the Application Suite software (Leica Biosystems). An HCX Plan-Apochromat CS 63× 1.4 NA objective (Leica Biosystems) was used for all acquisitions. Acquisition of Klp59D KD whole-mount testes slides was made using an epifluorescence axioscope Z1 imager (ZEISS) with an EC Plan-Neofluar 10×/0.3 Ph1 objective (ZEISS), photometrics CoolSNAP MYO camera (Photometrics), and Metavue 18.104.22.168 software. All images were processed with ImageJ. Figures were created with Adobe Photoshop CS5. Unless stated in the figure legends, only contrasts and offset were adjusted.
Squashes were performed on a 12-mm-diameter round coverslip with a 44 × 60-mm overlaying coverslip. Immunofluorescence protocols were the same as in the Immunofluorescence section using either PFA or methanol fixation. Images were acquired using an Elyra PS.1 system (ZEISS) equipped with a PCO edge 5.5 camera and ZEN 2012 SP2 software (black edition). The objective used for all acquisitions is a Plan-Apochromat 63× 1.4 NA.
Testes of young adults or pupae were dissected in PBS at room temperature, placed in a drop of PBS or PBS/0.5% FCS on glass-bottom poly-lysine–coated (Sigma-Aldrich) Petri dishes (Will-Co). Cells were pulled out of the testes using thinned capillaries and left to attach for 5–15 min. For some experiments, membranes were labeled using CellMask Deep Red Plasma membrane stain (Invitrogen) diluted at 1/50 in a drop of Sang and Shields M3 Insect Medium (Sigma-Aldrich).
Samples were processed as previously described (Enjolras et al., 2012; Vieillard et al., 2015). Antennae or testes were collected in PBS and fixed in 2% glutaraldehyde, 0.5% PFA, and 0.1 M sodium cacodylate, pH 7.4, for 48 h at 4°C. Samples were rinsed in 0.15 M sodium cacodylate, pH 7.4, and postfixed in 1% OsO4 (4 h for antennae and 1 h for testes). Samples were dehydrated through ethanol series and propylene oxide. Samples were substituted in 3 vol propylene oxide/1 vol resin (2 × 30 min), 1 vol propylene oxide/1 vol resin (2 × 30 min), and then 1 vol propylene oxide/3 vol resin (2 × 30 min) and finally embedded in epon medium (Fluka). Ultrathin sections were cut on an ultramicrotome (UC7; Leica Biosystems) and contrasted manually in methanol/uranyl acetate 7% and aqueous lead citrate. Contrasted sections were observed on a transmission EM (CM120; Philips) at 120 kV. Images were acquired with a 2k × 2k digital camera (ORIUS 200; Gatan) and digital micrograph software and processed with Photoshop CS5.
Quantifications of centriole and TZ lengths were performed on sum projections of confocal stacks made with identical settings in control or mutant situation, such to avoid saturated signal. The intensity profile along the centriole or TZ was plotted. Length was measured between the first pixel and the last pixel above the background threshold. Quantification of Klp59D and Cep290 intensities was performed using ImageJ and by measuring the sum of pixel intensity in a defined region encompassing the centrioles. Background intensity was subtracted by measuring the sum of pixel intensity in an adjacent region of the same area next to centrioles. Statistical analyses and graphs were made using Prism 7 software.
Quantification results are represented as scatter plots with the mean and SD on all figures. Statistical significance was determined by a two-tailed unpaired Student’s t test (Prism 6 software; ns, P > 0.05; *, P ≤ 0.05; **, P ≤ 0.01; ***, P ≤ 0.001; ****, P ≤ 0.0001).
1- or 2-d-old males were crossed individually with three w1118 virgin females. After 5 d, crosses with at least one dead fly were eliminated from the test. Mated flies were discarded from conserved crosses. All flies that hatched out from the crosses were counted.
Proteins were extracted from 48-h pupae (15) testes. Fusion proteins were revealed using a rabbit anti-GFP antibody (1/2,500; Abcam).
Online supplemental material
Fig. S1 shows the localization of MKS components in wild-type or B9d2, tctnΔ mutant Drosophila antennae. Fig. S2 shows the dynamics of TZ components in the male germ cells. Fig. S3 completes the phenotypic description of dila81; cby1 mutant germ cells, including transmission EM analysis, Rab8 expression, and MKS1 or Cep290 expression levels. Fig. S4 shows IF analysis and quantification of MKS and Cep290 components in cby1 or dila81 mutant male germ cells. Fig. S5 completes the phenotypic description of Klp59D KD testes, including EM observations.
